Xilence Performance A+ XN330 | XP750R12. Total power: 750 W, AC input voltage: 200 – 240 V, AC input frequency: 50 Hz. Motherboard power connector: 20-pin ATX, Motherboard power cable length: 5.5 cm, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Certification: 80PLUS certification
XN330 | XP750R12
The Gaming GOLD Series is a PC power supply series with a fixed cable harness, as well as a 750W ARGB variant. The noble design with its black powder coating, the 120mm silent, black or transparent fan and the fan grille emphasizes the valuable character of this series.
The maximum voltage stability and the six integrated safety circuits ensure safe operation even in heated workflows or gaming sessions. The power supplies are suitable for the highest demands in gaming, multi-media application and streaming areas and have low power consumption during these intensive phases. The power supplies achieve the 80+ GOLD requirements.
The Gaming GOLD Series is a PC power supply series with a fixed cable harness, as well as a 750W ARGB variant. The noble design with its black powder coating, the 120mm silent, black or transparent fan and the fan grille emphasizes the valuable character of this series.
The maximum voltage stability and the six integrated safety circuits ensure safe operation even in heated workflows or gaming sessions. The power supplies are suitable for the highest demands in gaming, multi-media application and streaming areas and have low power consumption during these intensive phases. The power supplies achieve the 80+ GOLD requirements.
Power
Total power: 750 W
AC input voltage: 200 – 240 V
AC input frequency: 50 Hz
Input current: 6.3 A
Power Factor Correction (PFC) type: Active
Combined power (+3.3V): 66 W
Combined power (+5V): 100 W
Combined power (-12V): 6 W
Combined power (+5Vsb): 15 W
Max output current (+12V): 62.5 A
Power protection features: Over power, Over voltage, Short circuit, Under voltage
Ports & interfaces
Motherboard power connector: 20-pin ATX
Motherboard power cable length: 5.5 cm
Number of SATA power connectors: 6
PCI Express power connectors (6+2 pin): 3
Feature: CPU power connector (4+4 pin)
Feature: ATX power connector (20+4 pin)
Feature: PCI Express connector
Cabling type: Non-Modular
Performance
80 PLUS certification: 80 PLUS Gold
Supported motherboard form factors: ATX
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 2.52
Feature: Silent mode
Bearing technology: HDB
Design
Product colour: Black
Cooling type: Active
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Fan location: Top
Feature: On/off switch
Certificates
Certification: 80PLUS certification
Weight & dimensions
Width: 198 mm
Depth: 247 mm
Height: 98 mm
Weight: 2.3 kg
Total power: 750 W
AC input voltage: 200 – 240 V
AC input frequency: 50 Hz
Input current: 6.3 A
Power Factor Correction (PFC) type: Active
Combined power (+3.3V): 66 W
Combined power (+5V): 100 W
Combined power (-12V): 6 W
Combined power (+5Vsb): 15 W
Max output current (+12V): 62.5 A
Power protection features: Over power, Over voltage, Short circuit, Under voltage
Ports & interfaces
Motherboard power connector: 20-pin ATX
Motherboard power cable length: 5.5 cm
Number of SATA power connectors: 6
PCI Express power connectors (6+2 pin): 3
Feature: CPU power connector (4+4 pin)
Feature: ATX power connector (20+4 pin)
Feature: PCI Express connector
Cabling type: Non-Modular
Performance
80 PLUS certification: 80 PLUS Gold
Supported motherboard form factors: ATX
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 2.52
Feature: Silent mode
Bearing technology: HDB
Design
Product colour: Black
Cooling type: Active
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Fan location: Top
Feature: On/off switch
Certificates
Certification: 80PLUS certification
Weight & dimensions
Width: 198 mm
Depth: 247 mm
Height: 98 mm
Weight: 2.3 kg
