Trendnet TPE-318GI. Ethernet interface type: 10 Gigabit Ethernet, Ethernet LAN data rates: 2500,10000 Mbit/s, Power over Ethernet (PoE) type supported: PoE++ (4PPoE). Product colour: Black, Maximum operating distance: 100 m. Power consumption (max): 0.7 W, Total Power over Ethernet (PoE) budget: 90 W. Certification: CE FCC. Width: 109.7 mm, Depth: 70 mm, Height: 28 mm
TRENDnet’s 10G PoE++ Injector, model TPE-318GI, combines electrical power with a 10GBASE-T network connection to produce a 10G PoE++ network signal. Auto-sensing technology conveniently delivers the correct wattage needed to power your PoE, PoE+ and PoE++ devices. Connect the 10G PoE++ injector to a non-PoE switch, and then run an Ethernet cable with data + power to network a PoE, PoE+ or PoE++ device up to 100 meters (328 ft.) over Cat6A or better cabling. Network PoE devices such as wireless access points, IP cameras, VoIP phone systems, IPTV decoders, access controls, and more.
Network
Ethernet interface type: 10 Gigabit Ethernet
Ethernet LAN data rates: 2500,10000 Mbit/s
Feature: Power over Ethernet (PoE)
Power over Ethernet (PoE) type supported: PoE++ (4PPoE)
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u
Cable types supported: Cat5e, Cat6, Cat6a
Features
Product colour: Black
Maximum operating distance: 100 m
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
RJ-45 input ports: 1
RJ-45 output ports: 1
Power
Power consumption (max): 0.7 W
Total Power over Ethernet (PoE) budget: 90 W
Certificates
Certification: CEFCC
Operational conditions
Operating temperature (T-T): 0 – 50 °C
Weight & dimensions
Width: 109.7 mm
Depth: 70 mm
Height: 28 mm
Weight: 672 g
Ethernet interface type: 10 Gigabit Ethernet
Ethernet LAN data rates: 2500,10000 Mbit/s
Feature: Power over Ethernet (PoE)
Power over Ethernet (PoE) type supported: PoE++ (4PPoE)
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u
Cable types supported: Cat5e, Cat6, Cat6a
Features
Product colour: Black
Maximum operating distance: 100 m
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
RJ-45 input ports: 1
RJ-45 output ports: 1
Power
Power consumption (max): 0.7 W
Total Power over Ethernet (PoE) budget: 90 W
Certificates
Certification: CEFCC
Operational conditions
Operating temperature (T-T): 0 – 50 °C
Weight & dimensions
Width: 109.7 mm
Depth: 70 mm
Height: 28 mm
Weight: 672 g
