Trendnet TI-PG62B. Switch type: Unmanaged, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 4. Full duplex. MAC address table: 1024 entries, Switching capacity: 12 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z. Power over Ethernet (PoE). Wall mountable
TRENDnet’s TI-PG62B is a reliable IP30 unmanaged hardened DIN-rail PoE+ switch with a rugged housing rated for extreme industrial environments. It offers 4 Gigabit PoE+ ports, two dedicated SFP slots and a 12 Gbps switching capacity. Dual redundant 12 – 56 VDC power inputs and a power failure alarm relay.
Management features
Switch type: Unmanaged
Switch layer: L2
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 4
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 4
SFP module slots quantity: 2
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Feature: Full duplex
Feature: Auto-negotiation
Data transmission
Switching capacity: 12 Gbit/s
Throughput: 8.9 Mpps
MAC address table: 1024 entries
Feature: Store-and-forward
Feature: Jumbo frames support
Jumbo frames: 9000
Design
Product colour: Black
Housing material: Metal
LED indicators: Yes
International Protection (IP) code: IP30
Feature: Wall mountable
Feature: DIN rail mounting
Performance
Buffer size: 1024 KB
Mean time between failures (MTBF): 510304 h
Power
Feature: Redundant power supply (RPS) support
Input voltage: 12 – 56
Power consumption (max): 5.76 W
Power protection features: Overload
Power over Ethernet (PoE)
Feature: Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 4
Total Power over Ethernet (PoE) budget: 120 W
Other features
Feature: Terminal block port
Operational conditions
Operating temperature (T-T): -40 – 75 °C
Weight & dimensions
Width: 143 mm
Depth: 105 mm
Height: 45 mm
Weight: 700 g
Packaging content
Feature: Quick start guide
Packaging data
Feature: Mounting brackets included
Certificates
Certification: FCC, CERoHS
Logistics data
Harmonized System (HS) code: 85176990
Switch type: Unmanaged
Switch layer: L2
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 4
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 4
SFP module slots quantity: 2
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Feature: Full duplex
Feature: Auto-negotiation
Data transmission
Switching capacity: 12 Gbit/s
Throughput: 8.9 Mpps
MAC address table: 1024 entries
Feature: Store-and-forward
Feature: Jumbo frames support
Jumbo frames: 9000
Design
Product colour: Black
Housing material: Metal
LED indicators: Yes
International Protection (IP) code: IP30
Feature: Wall mountable
Feature: DIN rail mounting
Performance
Buffer size: 1024 KB
Mean time between failures (MTBF): 510304 h
Power
Feature: Redundant power supply (RPS) support
Input voltage: 12 – 56
Power consumption (max): 5.76 W
Power protection features: Overload
Power over Ethernet (PoE)
Feature: Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 4
Total Power over Ethernet (PoE) budget: 120 W
Other features
Feature: Terminal block port
Operational conditions
Operating temperature (T-T): -40 – 75 °C
Weight & dimensions
Width: 143 mm
Depth: 105 mm
Height: 45 mm
Weight: 700 g
Packaging content
Feature: Quick start guide
Packaging data
Feature: Mounting brackets included
Certificates
Certification: FCC, CERoHS
Logistics data
Harmonized System (HS) code: 85176990
