Trendnet TEG-S380. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 16000 entries, Switching capacity: 40 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z. DC input voltage: 12 V. Wall mountable
Expand your network’s bandwidth and reduce digital bottlenecks with TRENDnet’s Unmanaged 2.5G Switches. These 2.5G network switches come equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over your existing Cat5e or better cabling. Each high-speed 2.5G switch features a durable metal enclosure and can be mounted to the wall for setup flexibility. The fanless design lowers energy consumption and eliminates distracting operating noise. TRENDnet’s reliable 2.5G switches are cost-effective solutions to increase your network’s throughput.
2.5G Ports
Equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over existing Cat5e or better cabling.
Wall Mountable
The 2.5G switches feature metal housing with a convenient wall mountable design for greater installation flexibility.
Fanless
The fanless design of the 2.5G switches lowers energy consumption costs and eliminates operating noise.
Easy Installation
No configuration needed, simply connect network devices to the 2.5G Ethernet switch
2.5G Ports
Equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over existing Cat5e or better cabling
Fanless
Fanless design lowers energy consumption and eliminates operating noise
Housing Design
Sturdy metal housing
Wall Mountable
Features a convenient wall mountable design for greater installation flexibility
Jumbo Frame
Sends larger packets, or Jumbo Frames (up to 12KB) for increased performance
LED Indicators
LED indicators on this 2.5G switch conveys port status
Switch type: Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Feature: Full duplex
Feature: Half duplex
Ethernet LAN data rates: 10,100,1000 Mbit/s
Data transmission
Switching capacity: 40 Gbit/s
Forwarding rate: 29.76 Mpps
MAC address table: 16000 entries
Feature: Jumbo frames support
Jumbo frames: 12000
Design
Product colour: Black
Housing material: Metal
LED indicators: Yes
Feature: Wall mountable
Performance
Mean time between failures (MTBF): 1401356 h
Power
Feature: Power supply included
AC input voltage: 100 – 240 V
AC input frequency: 50 – 60 Hz
DC input voltage: 12 V
Input current: 1.5 A
Power consumption (max): 12.4 W
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Operating relative humidity (H-H): 0 – 90%
Weight & dimensions
Width: 240 mm
Depth: 103 mm
Height: 26 mm
Weight: 600 g
Packaging content
Feature: Quick start guide
Certificates
Certification: FCC, CE
Logistics data
Harmonized System (HS) code: 85176990
