TP-Link Omada 8-Port Gigabit Smart Switch with 4-Port PoE+. Switch type: Managed, Switch layer: L2/L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 8000 entries, Switching capacity: 16 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE…. Power over Ethernet (PoE). Rack mounting
TP-Link’s brand new Omada smart switches provide huge upgrade comparing with previous versions. The switches can be managed by Omada SDN Controller, which provides professional and reliable one-step solutions. Integrated L2 and L2+ features such as 802.1Q VLAN, QoS, IGMP Snooping and static routing provide cost-effective networking solutions for small and medium-sized businesses without sacrificing enhanced usability and strong performance.
Management features
Switch type: Managed
Switch layer: L2/L2+
Feature: Quality of Service (QoS) support
Feature: Web-based management
Feature: ARP inspection
Feature: System event log
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
Feature: Port mirroring
Feature: Flow control support
Feature: Link aggregation
Feature: Broadcast storm control
Feature: Rate limiting
Feature: Auto MDI/MDI-X
Feature: Spanning tree protocol
Feature: Auto-negotiation
Feature: VLAN support
Number of VLANs: 4094
Data transmission
Switching capacity: 16 Gbit/s
Forwarding rate: 11.9 Mpps
MAC address table: 8000 entries
Number of queues: 8
Feature: Jumbo frames support
Jumbo frames: 9000
Packet buffer memory: 4.1 MB
Security
DHCP features: DHCP client, DHCP relay, DHCP snooping, DHCPv6 server, DHCPv6 snooping
Feature: IGMP snooping
Security algorithms: 802.1x RADIUS
Feature: MAC address filtering
Authentication: MAC-based authentication, Web-based authentication
Authentication type: RADIUS
Multicast features
Feature: Multicast support
Protocols
Management protocols: SNMPv1/v2c/v3
IPv4 & IPv6 features: IPv6 Telnet, IPv6 ping, IPv6 tracert
Design
Feature: Rack mounting
Product colour: Black
LED indicators: Yes
Performance
Feature: Fanless
Power
Feature: Power supply included
Power consumption (max): 77.3 W
Power over Ethernet (PoE)
Feature: Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 4
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Storage temperature (T-T): -40 – 70 °C
Operating relative humidity (H-H): 10 – 90%
Storage relative humidity (H-H): 5 – 90%
Heat dissipation: 263.6 BTU/h
Weight & dimensions
Width: 209 mm
Depth: 126 mm
Height: 26 mm
Packaging content
Feature: Manual
Packaging data
Package type: Box
Certificates
Certification: CE, FCC, RoHS
