SUNIX Group SER6437AL. Host interface: PCIe, Output interface: RS-232. Certification: CE, FCC, VCCI, BSMI. Baud rate: 115.2 Kbit/s, FIFO (First In, First Out): 128 B, Stop bits: 1, 1.5, 2. Width: 65 mm, Height: 68 mm. Package type: Box
SUNIX SER6437AL, PCI Express serial communication board meets the PCI Express Base Specification Revision 2.0, allows users to add or expand two RS-232 COM ports on PC-based system to use serial devices further. It is compatible with PCI Express x1, x2, x4, x8 and x16 lane Bus allowing it to be installed in any PC-based system with low profile bracket structure. The majorities of today’s motherboard is not equipped with serial ports or only have one serial port. With SUNIX PCI Express serial board, users can add one serial port to their system, allowing them to use serial devices further. SUNIX SER6437AL card has 128-bytes onboard FIFO buffer and compatible with 16C950 UART specifications. It is designed with SUNIX UART controller, SUN2212 and as well built with many of SUNIX advanced features and technologies, making it the best solution for commercial and industrial automation applications.
Ports & interfaces
Host interface: PCIe
Output interface: RS-232
SATA revision: 2.0
Design
Feature: Internal
Certification: CE, FCC, VCCI, BSMI
Features
Baud rate: 115.2 Kbit/s
FIFO (First In, First Out): 128 B
Stop bits: 1, 1.5, 2
Feature: Flow control support
Parity bit: Even, Mark, No, Odd, Space
Flow Control type: No, RTS/CTS, XON/XOFF
Feature: Plug and Play
Operational conditions
Operating temperature (T-T): 0 – 60 °C
Storage temperature (T-T): -20 – 85 °C
Operating relative humidity (H-H): 5 – 95%
System requirements
Windows operating systems supported: Yes
Linux operating systems supported: Yes
Weight & dimensions
Width: 65 mm
Height: 68 mm
Packaging data
Quantity: 1
Feature: Mounting brackets included
Feature: Quick installation guide
Package type: Box
Logistics data
Harmonized System (HS) code: 84733020
Host interface: PCIe
Output interface: RS-232
SATA revision: 2.0
Design
Feature: Internal
Certification: CE, FCC, VCCI, BSMI
Features
Baud rate: 115.2 Kbit/s
FIFO (First In, First Out): 128 B
Stop bits: 1, 1.5, 2
Feature: Flow control support
Parity bit: Even, Mark, No, Odd, Space
Flow Control type: No, RTS/CTS, XON/XOFF
Feature: Plug and Play
Operational conditions
Operating temperature (T-T): 0 – 60 °C
Storage temperature (T-T): -20 – 85 °C
Operating relative humidity (H-H): 5 – 95%
System requirements
Windows operating systems supported: Yes
Linux operating systems supported: Yes
Weight & dimensions
Width: 65 mm
Height: 68 mm
Packaging data
Quantity: 1
Feature: Mounting brackets included
Feature: Quick installation guide
Package type: Box
Logistics data
Harmonized System (HS) code: 84733020
