StarTech.com Cisco SFP-GE-T Compatible SFP Module – 1000BASE-T – SFP to RJ45 Cat6/Cat5e – 10/100/1000 Mbps – RJ-45 100m – Cisco IE3400, IE3300, IE3200. SFP transceiver type: Copper, Maximum data transfer rate: 1250 Mbit/s, Interface type: SFP. Product colour: Silver, Mean time between failures (MTBF): 4655371 h. Power consumption (typical): 1.3 W. Compliance certificates: RoHS, Certification: CE, FCC, UL, REACH. Width: 13 mm, Depth: 70 mm, Height: 13 mm
The SFPC1110 is a Cisco SFP-GE-T compatible copper transceiver module that has been designed, programmed and tested to work with Cisco® brand switches and routers. It delivers dependable 1GbE (1000 Mbps) connectivity over copper cable, for 1000BASE-T compliant networks, with a maximum distance of up to 100 m (328 ft).
Technical Specifications:
• Maximum Data Transfer Rate: 1.25 Gbps
• Type: Copper
• Connection Type: RJ45 Connector
• Maximum Transfer Distance: 100 m (328 ft)
• MTBF: 4,655,371 hours
• Power Consumption: Less than 1.3 Watts
• Digital Diagnostics Monitoring (DDM): No
This SFP copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
SFP transceiver type: Copper
Maximum data transfer rate: 1250 Mbit/s
Interface type: SFP
Fiber optic connector: SFP
Maximum transfer distance: 100 m
Networking standards: IEEE 802.3ab
Cabling technology: 1000BASE-T
Ethernet LAN (RJ-45) ports: 1
Feature: Auto MDI/MDI-X
Feature: Auto-negotiation
Feature: Digital Diagnostics Monitoring (DDM)
Features
Product colour: Silver
Feature: Hot-swap
Mean time between failures (MTBF): 4655371 h
Power
Power consumption (typical): 1.3 W
Certificates
Compliance certificates: RoHS
Certification: CE, FCC, UL, REACH
Operational conditions
Operating temperature (T-T): 0 – 70 °C
Storage temperature (T-T): -40 – 85 °C
Operating relative humidity (H-H): 30 – 70%
Weight & dimensions
Width: 13 mm
Depth: 70 mm
Height: 13 mm
Weight: 46 g
Packaging content
Quantity per pack: 1 pc(s)
Packaging data
Package width: 91 mm
Package depth: 113 mm
Package height: 33 mm
Package weight: 55 g
Logistics data
Master (outer) case width: 206 mm
Master (outer) case length: 298 mm
Harmonized System (HS) code: 85369010
Master (outer) case height: 248 mm
Products per master (outer) case: 36 pc(s)
