StarTech.com MSA Uncoded SFP Module – 1000BASE-LX – 1GbE Single Mode Fiber (SMF) Optic Transceiver – 1GE Gigabit Ethernet SFP – LC 10km – 1310nm – DDM. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1250 Mbit/s, Interface type: SFP. Product colour: Silver, Housing material: Aluminium. Power consumption (typical): 1 W. Compliance certificates: RoHS, Certification: CE, FCC, UR. Width: 15 mm, Depth: 59 mm, Height: 12 mm
The SFP1000LXST is an MSA compliant fiber SFP transceiver that’s designed, programmed and tested to work with 1000BASE-LX compatible MSA switches and routers. The SFP transceiver module supports a maximum distance of up to 10 km (6.2 mi) and delivers dependable 1 GbE connectivity over fiber cabling.
Technical Specifications:
• Wavelength: 1310nm
• Maximum Data Transfer Rate: 1.25 Gbps
• Type: Single Mode Fiber
• Connection Type: LC Connector
• Maximum Transfer Distance: 10 km (6.2 mi)
• Power Consumption: Less than 1 Watt
• DDM: Yes
This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.
SFP transceiver type: Fiber optic
Maximum data transfer rate: 1250 Mbit/s
Interface type: SFP
Feature: Single-mode fiber (SMF) supported
Fiber optic connector: LC
SFP transceiver standard: LX
Maximum transfer distance: 10000 m
Wavelength: 1310 nm
Networking standards: IEEE 802.3z
Duplex system: Full
Feature: Digital Diagnostics Monitoring (DDM)
Features
Product colour: Silver
Housing material: Aluminium
Feature: Hot-Plug support
Power
Power consumption (typical): 1 W
Certificates
Compliance certificates: RoHS
Certification: CE, FCC, UR
Operational conditions
Operating temperature (T-T): 0 – 70 °C
Storage temperature (T-T): -40 – 85 °C
Operating relative humidity (H-H): 5 – 95%
Weight & dimensions
Width: 15 mm
Depth: 59 mm
Height: 12 mm
Weight: 18 g
Packaging content
Quantity per pack: 1 pc(s)
Packaging data
Package width: 92 mm
Package depth: 113 mm
Package height: 33 mm
Package weight: 47 g
Logistics data
Master (outer) case width: 200 mm
Master (outer) case length: 302 mm
Harmonized System (HS) code: 85369010
Master (outer) case height: 256 mm
Products per master (outer) case: 35 pc(s)
Country of origin: China
