PowerWalker VFI 3000 ICT IoT. UPS topology: Double-conversion (Online), Output power capacity: 3 kVA, Output power: 3000 W. AC outlet types: C13 coupler, C19 coupler, Power plug: C20 coupler, AC outlets quantity: 9 AC outlet(s). Battery capacity: 9 Ah, Battery voltage: 12 V, Battery recharge time: 3 h. Form factor: Tower, Product colour: Black, Cooling type: Active. Cables included: Input power cable, Output power cable, USB cable
This UPS series utilizes double conversion technology and features unity power factor, ensuring the availability of your mission-critical equipment and providing clean output power to your sensitive loads. Multiple optional accessories such as external battery packs, communication cards and a WLAN adapter enhance the functionality of the UPS.
Stay up to date everywhere and anytime.
UPS topology: Double-conversion (Online)
Output power capacity: 3 kVA
Output power: 3000 W
Waveform: Pure sine
Input operation voltage (min): 160 V
Input operation voltage (max): 300 V
Input frequency: 40/70 Hz
Output operation voltage (min): 200 V
Output operation voltage (max): 240 V
Output voltage regulation: 1%
Response time: 0 ms
Input power factor: 0.99
Output power factor: 1
Crest factor: 3:1
Feature: ECO mode
Feature: Emergency Power Off (EPO)
Output voltage Total Harmonic Distortion (THD): 1%
Input current Total Harmonic Distortion (THD): 5%
Noise level: 50 dB
Power protection features: Overload
Ports & interfaces
AC outlet types: C13 coupler, C19 coupler
Power plug: C20 coupler
AC outlets quantity: 9 AC outlet(s)
Feature: USB port
Feature: Serial interface
Serial interface type: RS-232
Serial ports quantity: 1
Feature: Emergency Power Off (EPO) connector
Battery
Battery capacity: 9 Ah
Battery voltage: 12 V
Number of batteries supported: 6
Battery recharge time: 3 h
Charging current: 1.5 A
Design
Form factor: Tower
Cooling type: Active
Feature: Built-in fan
Product colour: Black
Display type: LCD
LED indicators: Yes
Operational conditions
Operating temperature (T-T): 0 – 45 °C
Operating relative humidity (H-H): 0 – 95%
Packaging content
Cables included: Input power cable, Output power cable, USB cable
Feature: Manual
Weight & dimensions
Width: 192 mm
Depth: 428 mm
Height: 318 mm
Weight: 26.4 kg
Packaging data
Package width: 590 mm
Package depth: 330 mm
Package height: 475 mm
Package weight: 28.9 kg
Logistics data
Harmonized System (HS) code: 85078000
