NETGEAR GS305PP. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 4. Full duplex. MAC address table: 2000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. DC input voltage: 54 V. Power connector: DC-in jack. Power over Ethernet (PoE). Wall mountable
NETGEAR 300 Series Gigabit Ethernet Unmanaged Switches provide easy, reliable, and affordable network connectivity for home and small offices. With these unmanaged plug-and-play switches, you can expand your network connections to multiple devices instantly. The GS305P/GS305PP and GS308P with Power-over-Ethernet (PoE) provides power and data from a single Ethernet (CAT-5) cable to devices such as IP cameras, VoIP/Internet-based phones, wireless access points, etc. Just step up to GS316, GS324 or GS348 directly to avoid congestion due to stacking up lower port count switches and be ready for future expansion.
Switch type: Unmanaged
Feature: Quality of Service (QoS) support
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 4
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 5
Power connector: DC-in jack
Network
Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Feature: Full duplex
Feature: Auto MDI/MDI-X
Feature: Auto-sensing
Feature: Auto-negotiation
Feature: Cable length detection
Data transmission
Switching capacity: 10 Gbit/s
Forwarding rate: 1.448 Mpps
MAC address table: 2000 entries
Latency (1 Gbps): 2.4 µs
Feature: Jumbo frames support
Jumbo frames: 9216
Packet buffer memory: 128 MB
Design
Product colour: Black
Housing material: Metal
Feature: Reset button
LED indicators: Activity, Link, PoE, Power
Feature: Wall mountable
Performance
Mean time between failures (MTBF): 6710127 h
Power
Power source: DC
DC input voltage: 54 V
Input current: 1.66 A
Power consumption (typical): 2.89 W
Power consumption (max): 88.89 W
Power over Ethernet (PoE)
Feature: Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 4
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 83 W
Other features
Warranty period: 3 year(s)
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Storage temperature (T-T): -20 – 70 °C
Operating relative humidity (H-H): 10 – 90%
Storage relative humidity (H-H): 5 – 95%
Heat dissipation: 304 BTU/h
Weight & dimensions
Width: 158 mm
Depth: 101 mm
Height: 29 mm
Weight: 410 g
Packaging content
Feature: Manual
Packaging data
Package width: 269 mm
Package depth: 73 mm
Package height: 215 mm
Package weight: 1.3 kg
Technical details
Shipping (inner) case height: 37.5 cm
Shipping (inner) case width: 45.1 cm
Shipping (inner) case length: 25.5 cm
Shipping (inner) case net weight: 15.1 kg
Products per shipping (inner) case: 10 pc(s)
Certificates
Certification: CE Mark, FCC Part 15 Class B, IC Class B, RCM, CCC, VCCI, CB, CE VD, CCC
Logistics data
Master (outer) case width: 237 mm
Master (outer) case length: 469 mm
Master (outer) case height: 306 mm
Master (outer) case gross weight: 8.52 kg
Products per master (outer) case: 6 pc(s)
