Neomounts FPMA-D700D4 Monitor arm 19-30". Mounting: Clamp, Maximum weight capacity: 8 kg, Minimum screen size: 48.3 cm (19"), Maximum screen size: 76.2 cm (30"), Minimum VESA mount: 75 x 75 mm, Maximum VESA mount: 100 x 100 mm. Height adjustment, Swivel angle range: 0 – 180°, Tilt angle range: 0 – 180°. Product colour: Black
Neomounts versatile tilt (180°), rotate (360°) and swivel (180°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The mount is manually height adjustable from 0 to 70 centimetres. Depth 15 centimetres. An innovative cable management conceals and routes cables from mount to flat screen. Hide your cables to keep the workplace nice and tidy.
Neomounts FPMA-D700D4 has two pivot points and is suitable for screens up to 30″ (76 cm). The weight capacity of this product is 8 kg each screen. The desk mount is suitable for screens that meet VESA hole pattern 75×75 or 100x100mm. Different hole patterns can be covered using Neomounts VESA adapter plates.
By using an ergonomic mount neck- and back complaints can be avoided. Ideal for use in offices and on counters or in a reception area.
All installation material is included with the product.
Maximum weight capacity: 8 kg
Minimum screen size: 48.3 cm (19″)
Number of displays supported: 4
Maximum weight capacity (per display): 8 kg
Maximum screen size: 76.2 cm (30″)
Mounting: Clamp
Mounting type: Desk
Minimum VESA mount: 75 x 75 mm
Maximum VESA mount: 100 x 100 mm
Panel mounting interface: 100 x 100,75 x 75 mm
Desk thickness (max): 9 cm
Ergonomics
Feature: Height adjustment
Height adjustment type: Manual
Height adjustment range: 220 – 700 mm
Depth adjustment range: 0 – 150 mm
Feature: Tilt adjustment
Tilt angle range: 0 – 180°
Feature: Swivelling
Swivel angle: 180°
Swivel angle range: 0 – 180°
Feature: Rotating
Angle of rotation: 360°
Design
Housing material: Steel
Product colour: Black
Weight & dimensions
Width: 830 mm
Depth: 150 mm
Height: 700 mm
Weight: 13.9 kg
Packaging data
Package width: 830 mm
Package depth: 555 mm
Package height: 180 mm
Package weight: 12.6 kg
Other features
Width adjustment range: 520 – 830 mm
Logistics data
Master (outer) case width: 830 mm
Master (outer) case length: 555 mm
Master (outer) case height: 180 mm
Master (outer) case gross weight: 14.2 kg
Products per master (outer) case: 1 pc(s)
Country of origin: Taiwan
Master (outer) case net weight: 12.6 kg
Harmonized System (HS) code: 7326909890
Products per pallet (EU): 14 pc(s)
