MOES HP02 ZigBee mmWave Presence Sensor
Discover the MOES HP02 ZigBee mmWave Presence Sensor—a compact yet advanced device that detects both motion and subtle signs of presence, such as breathing. Thanks to radar technology, it operates independently of ambient temperature, light, or airflow, offering precise real-time measurements. Compatibility with the Smart Life, MOES, and Tuya apps allows for convenient management and instant notifications, while up to 30 days of history storage facilitates activity analysis. The compact design with a magnetic base enables flexible installation, and the wired power supply ensures stable, uninterrupted operation. This solution elevates the level of automation and security in your home.
Presence detection taken to a whole new level
Advanced mmWave technology allows for the detection not only of movement but also of a person at rest. The sensor analyzes signals such as heartbeat, breathing, and micro-movements, ensuring it doesn’t “lose track” of the user even while sitting or sleeping. Additionally, it can monitor the current distance and duration of presence in the room, opening up new possibilities for automation—from lighting control to security system management.
Precision Independent of Conditions
The sensor’s operation is not affected by temperature, light sources, or air movement, eliminating the typical limitations of classic PIR sensors. Radar waves penetrate materials such as fabric, glass, plastic, and insulation, allowing the device to operate discreetly and effectively even in challenging installation conditions. The wide detection range covers various angles and distances (up to 180° at 3 meters, 140° at 5 meters, and 60° at 6 meters), allowing its operation to be tailored to a specific room.
Flexible installation and stable operation
The compact housing, with a diameter of just 49.66 mm, makes the sensor easy to integrate into any interior. The magnetic base allows for tilt adjustment up to 45° and full 360° rotation, which significantly facilitates precise positioning of the detection field. Wired power eliminates the need for battery replacement and ensures continuous operation, which is particularly important in security and home automation systems.
Smart Control and Security
Integration with the Smart Life, MOES, and Tuya apps allows you to create automation scenarios and receive instant notifications of detected presence. The sensor can become part of an alarm system—when you leave the house, it automatically activates security measures by working with a ZigBee gateway and an alarm siren. Please note that a compatible ZigBee gateway is required for operation and must be purchased separately—it is responsible for communication and fully utilizing the device’s capabilities.
Included in the set
- presence sensor
- magnetic base
- USB charging cable
- user manual
| Manufacturer | MOES |
|---|---|
| Model | HP02 |
| Power supply | 5V=1A |
| Power consumption | 0.5W |
| Communication protocol | ZigBee |
| Light sensitivity range | 0-10000lux |
| Frequency | 24GHz–24.25GHz |
| Operating temperature | -10°C–40°C |
| Operating humidity | 0–95% relative humidity, non-condensing |
| Radar transmission power | 7.6dBm |
| Frequency band | 2.400–2.483GHz |
| Maximum transmission power | <+20 dBm |
