LogiLink CPV0059. Cable length: 50 m, Cable standard: Cat7, Cable shielding: S/FTP (S-STP), Product colour: Orange
Installation cable PrimeLine, Cat.7, S/FTP, orange, 50 m” from LogiLink Professional
LogiLink’s Cat.7 and Cat.7A cable offer maximum operating frequencies up to 1200 megahertz and are ideally suited for Ethernet networks with transmission rates of 10 Gbit/s and above. They are downward compatible with Cat.6A, Cat.6 or Cat.5 cabling. The 4 pair twisted pair cables are equipped with individual pair foils and an overall braid (S/FTP). This makes the LogiLink Cat.7 and Cat.7A cables ideal for future-proof structured cabling for 10GBASE-T Ethernet, 100BASE-TX or 1000BASE-T.
LogiLink’s Cat.7 and Cat.7A cable offer maximum operating frequencies up to 1200 megahertz and are ideally suited for Ethernet networks with transmission rates of 10 Gbit/s and above. They are downward compatible with Cat.6A, Cat.6 or Cat.5 cabling. The 4 pair twisted pair cables are equipped with individual pair foils and an overall braid (S/FTP). This makes the LogiLink Cat.7 and Cat.7A cables ideal for future-proof structured cabling for 10GBASE-T Ethernet, 100BASE-TX or 1000BASE-T.
Features
Product colour: Orange
Cable length: 50 m
Cable standard: Cat7
Cable shielding: S/FTP (S-STP)
Connector 1: No
Connector 2: No
Connector 1 gender: No
Connector 2 gender: No
Jacket material: Low smoke zero halogen (LSZH)
Cable shape: Round
Conductor material: Copper
Cable class: D
Cabling technology: 10GBase-T
Ethernet interface type: 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
AWG wire size: 23/1
Frequency: 1000 MHz
Feature: Plug and Play
Sustainability
Doesn’t contain: Halogen
Certificates
Compliance certificates: RoHS
Certification: ISO/IEC11801, ANSI/TIA-568-C.2, EN50173, IEC-61156-5
Weight & dimensions
Width: 270 mm
Depth: 100 mm
Height: 270 mm
Outer diameter: 7.5 mm
Weight: 2.6 kg
Packaging content
Quantity per pack: 1 pc(s)
Packaging data
Package width: 280 mm
Package depth: 115 mm
Package height: 280 mm
Package weight: 2.8 kg
Technical details
Feature: Sustainability compliance
Product colour: Orange
Cable length: 50 m
Cable standard: Cat7
Cable shielding: S/FTP (S-STP)
Connector 1: No
Connector 2: No
Connector 1 gender: No
Connector 2 gender: No
Jacket material: Low smoke zero halogen (LSZH)
Cable shape: Round
Conductor material: Copper
Cable class: D
Cabling technology: 10GBase-T
Ethernet interface type: 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
AWG wire size: 23/1
Frequency: 1000 MHz
Feature: Plug and Play
Sustainability
Doesn’t contain: Halogen
Certificates
Compliance certificates: RoHS
Certification: ISO/IEC11801, ANSI/TIA-568-C.2, EN50173, IEC-61156-5
Weight & dimensions
Width: 270 mm
Depth: 100 mm
Height: 270 mm
Outer diameter: 7.5 mm
Weight: 2.6 kg
Packaging content
Quantity per pack: 1 pc(s)
Packaging data
Package width: 280 mm
Package depth: 115 mm
Package height: 280 mm
Package weight: 2.8 kg
Technical details
Feature: Sustainability compliance
