LevelOne 24V DC Industrial Power Supply, 30W, DIN-Rail. Total power: 30 W, AC input voltage: 85 – 264 V, Peak power: 36 W. Mean time between failures (MTBF): 968100 h. Product colour: Black. Safety: UL60950-1, UL508, TUV EN61558-2-16, IEC60950-1, EAC TP TC 004, BSMI CNS14336-1 approved; Design…. Width: 90 mm, Depth: 54.5 mm, Height: 35 mm
The POW-2411 is a DIN-rail industrial power supply is ruggedized, universal input voltage range and full compliance with all important safety and EMC standards. It can be operated at full load across an ambient temperature range of -30 to 70 Celsius degree without need of additional cooling to guarantee quality for harsh industrial environment.
Power
Total power: 30 W
Peak power: 36 W
AC input voltage: 85 – 264 V
Power protection features: Over voltage, Overload, Short circuit
Performance
Mean time between failures (MTBF): 968100 h
Design
Product colour: Black
Operational conditions
Operating temperature (T-T): -30 – 70 °C
Operating relative humidity (H-H): 20 – 90%
Weight & dimensions
Width: 90 mm
Depth: 54.5 mm
Height: 35 mm
Weight: 120 g
Packaging data
Package width: 90 mm
Package depth: 54.5 mm
Package height: 35 mm
Package weight: 120 g
Logistics data
Harmonized System (HS) code: 84733020
Country of origin: China
Other features
Maximum current: 1.5 A
Technical features: 24V DC Out
Total power: 30 W
Peak power: 36 W
AC input voltage: 85 – 264 V
Power protection features: Over voltage, Overload, Short circuit
Performance
Mean time between failures (MTBF): 968100 h
Design
Product colour: Black
Operational conditions
Operating temperature (T-T): -30 – 70 °C
Operating relative humidity (H-H): 20 – 90%
Weight & dimensions
Width: 90 mm
Depth: 54.5 mm
Height: 35 mm
Weight: 120 g
Packaging data
Package width: 90 mm
Package depth: 54.5 mm
Package height: 35 mm
Package weight: 120 g
Logistics data
Harmonized System (HS) code: 84733020
Country of origin: China
Other features
Maximum current: 1.5 A
Technical features: 24V DC Out
