LevelOne 8-Port Fast Ethernet Switch. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 1024 entries, Switching capacity: 1.6 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x. Power connector: DC-in jack
Easy Configuration and Maintenance
The LevelOne FSW-0808TX does not require software configuration. Users can immediately use any features of this product simply by attaching the cables and turning on the power. For instant error detection, the switch is equipped with a full range of LEDs to help you monitor and troubleshoot problems on your network.
Compact Size Design
This switch is compact specially designed to fit on the desktop or in other space-limited locations. The FSW-0808TX provides an ideal solution for businesses that crave a reliable network to exchange large data files and multimedia information with bandwidth-starving workgroup, departments, and offices.
– Provides flexibility of 8 x 10/100BASE-TX ports
– 10/100Mbps-Full/Half-duplex, Auto-Negotiation, Auto-MDI/MDIX
– Supports 1K MAC address auto-learning and auto-aging
– IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
– Magnetic base for easy placement
– Quick and easy installation
Switch type: Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Power connector: DC-in jack
Network
Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX
Feature: Full duplex
Feature: Flow control support
Feature: Auto MDI/MDI-X
Feature: Auto-negotiation
Data transmission
Switching capacity: 1.6 Gbit/s
MAC address table: 1024 entries
Feature: Store-and-forward
Packet forwarding rate (100 Mbps): 148000 pps
Packet forwarding rate (10 Mbps): 14880 pps
Design
Product colour: Grey
LED indicators: Activity, Link, Power
Performance
Buffer size: 96 KB
Power
AC input voltage: 100 – 240 V
AC input frequency: 50 – 60 Hz
Output voltage: 5 V
Output current: 1 A
Power consumption (typical): 2.8 W
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Storage temperature (T-T): -40 – 70 °C
Operating relative humidity (H-H): 5 – 90%
Storage relative humidity (H-H): 10 – 90%
Weight & dimensions
Width: 125 mm
Depth: 69 mm
Height: 30 mm
Packaging content
Feature: Quick start guide
Packaging data
Feature: AC adapter included
Package width: 75 mm
Package depth: 130 mm
Package height: 90 mm
Package weight: 300 g
Certificates
Certification: FCC, CE, RoHS
Logistics data
Country of origin: China
Harmonized System (HS) code: 85176990
