Design
Colour name: Black
Product type: Laptop
Product colour: Black
Form factor: Clamshell
Housing material: Aluminium
Display back cover material: Aluminium
Market positioning: Business
Display
Display diagonal: 40.6 cm (16″)
Display resolution: 1920 x 1200 pixels
Touchscreen: No
HD type: WUXGA
Panel type: IPS
LED backlight: Yes
Native aspect ratio: 16:10
Anti-glare screen: Yes
Display brightness: 300 cd/m²
RGB colour space: NTSC
Colour gamut: 45%
Maximum refresh rate: 60 Hz
Contrast ratio (typical): 800:1
Processor
Processor manufacturer: Intel
Processor family: Intel Core Ultra 5
Processor generation: Intel Core Ultra (Series 2)
Processor model: 225U
Processor cores: 12
Processor threads: 14
Processor boost frequency: 4.8 GHz
Performance cores: 2
Efficient cores: 8
Low Power Efficient-cores: 2
Performance-core Max Turbo Frequency: 5.2 GHz
Efficient-core Max Turbo Frequency: 4.2 GHz
Low Power Efficient-core Max Turbo Frequency: 2.4 GHz
Performance-core base frequency: 2 GHz
Efficient-core base frequency: 1.7 GHz
Low Power Efficient-core Base Frequency: 700 MHz
Processor cache: 12 MB
Processor cache type: Smart Cache
Processor base power: 15 W
Maximum turbo power: 57 W
Neural processor unit (NPU)
Neural processor unit (NPU): Intel AI Boost
Sparsity support: Yes
Windows Studio effects support: Yes
AI datatype support on NPU: FP16, FP32, Int8
AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
NPU performance up to: 12 TOPs
Memory
Internal memory: 8 GB
Internal memory type: DDR5-SDRAM
Memory clock speed: 5600 MHz
Memory form factor: SO-DIMM
Memory layout (slots x size): 1 x 8 GB
Memory slots: 2x SO-DIMM
Maximum internal memory: 64 GB
Storage
Total storage capacity: 256 GB
Storage media: SSD
Total SSDs capacity: 256 GB
Number of SSDs installed: 1
SSD capacity: 256 GB
SSD interface: PCI Express 4.0
NVMe: Yes
SSD form factor: M.2
M.2 SSD size: 2242 (22 x 42 mm)
Optical drive type: No
Card reader integrated: No
Graphics
Discrete graphics card model: Not available
On-board graphics card: Yes
On-board GPU manufacturer: Intel
Discrete graphics card: No
On-board graphics card family: Intel® Graphics
On-board graphics card model: Intel® Graphics
Audio
Audio chip: Senary SN6147
Audio system: Dolby Atmos
Number of built-in speakers: 2
Speakers manufacturer: Harman Kardon
Speaker power: 2 W
Built-in microphone: Yes
Number of microphones: 2
Camera
Front camera: Yes
Front camera resolution: 1920 x 1080 pixels
Front camera HD type: Full HD
Infrared (IR) camera: Yes
Privacy camera: Yes
Privacy type: Privacy shutter
Network
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi standards: Wi-Fi 6E (802.11ax)
Mobile network connection: No
Antenna type: 2×2
WLAN controller model: Intel Wi-Fi 6E AX211
WLAN controller manufacturer: Intel
Ethernet LAN: Yes
Ethernet LAN data rates: 100,1000 Mbit/s
Bluetooth: Yes
Bluetooth version: 5.3
Near Field Communication (NFC): No
WWAN: Not installed
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
USB 3.2 Gen 2×2 Type-C ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
HDMI version: 2.1
Thunderbolt 4 ports quantity: 1
Intel® Thunderbolt 4: Yes
Combo headphone/mic port: Yes
USB Type-C DisplayPort Alternate Mode: Yes
USB Sleep-and-Charge: Yes
Performance
Motherboard chipset: Intel SoC
Keyboard
Pointing device: ThinkPad UltraNav
Numeric keypad: Yes
Keyboard backlit: Yes
Full-size keyboard: Yes
Keyboard language: German
Software
Operating system architecture: 64-bit
Operating system language: German
Operating system installed: Windows 11 Pro
Battery
Battery technology: Lithium-Ion (Li-Ion)
Battery capacity: 64 Wh
Power
AC adapter power: 65 W
AC adapter frequency: 50/60 Hz
AC adapter input voltage: 100 – 240 V
USB Type-C charging port: Yes
USB Power Delivery (USB PD): Yes
Security
Cable lock slot: Yes
Cable lock slot type: Kensington
Fingerprint reader: Yes
Smart card reader: No
Windows Hello: Yes
Trusted Platform Module (TPM): Yes
Trusted Platform Module (TPM) version: 2.0
Operational conditions
Operating temperature (T-T): 5 – 35 °C
Storage temperature (T-T): 5 – 43 °C
Operating relative humidity (H-H): 8 – 95%
Storage relative humidity (H-H): 5 – 95%
Maximum shipping altitude: 3048 m
Certificates
Compliance certificates: RoHS
Certification: ENERGY STAR,TCO,EPEAT Gold,RoHS
Sustainability
Sustainability certificates: ENERGY STAR, EPEAT Gold, ErP
Weight & dimensions
Width: 356 mm
Depth: 249 mm
Height (front): 1.01 cm
Height (rear): 1.71 cm
Weight: 1.63 kg
Packaging content
AC adapter included: Yes
