Lenovo ThinkCentre M70s Gen 6. Processor family: Intel Core Ultra 5, Processor model: 225. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 5600 MHz. Total storage capacity: 512 GB, Storage media: SSD. On-board graphics card model: Intel Graphics. Operating system installed: Windows 11 Pro, Operating system architecture: 64-bit. Power supply: 260 W. Chassis type: SFF. Product type: PC. Weight: 5.1 kg. Product colour: Black
Processor
Processor manufacturer: Intel
Processor family: Intel Core Ultra 5
Processor generation: Intel Core Ultra (Series 2)
Processor model: 225
Processor cores: 10
Processor threads: 10
Processor boost frequency: 4.9 GHz
Performance cores: 6
Efficient cores: 4
Performance-core Max Turbo Frequency: 4.9 GHz
Efficient-core Max Turbo Frequency: 4.4 GHz
Performance-core base frequency: 3.3 GHz
Efficient-core base frequency: 2.7 GHz
Processor cache: 20 MB
Processor cache type: Smart Cache
Processor base power: 65 W
Maximum turbo power: 121 W
Neural processor unit (NPU)
Neural processor unit (NPU): Intel AI Boost
Sparsity support: Yes
Windows Studio effects support: Yes
AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to: 23 TOPs
NPU performance up to: 13 TOPs
GPU performance up to: 4 TOPs
Memory
Internal memory: 16 GB
Maximum internal memory: 128 GB
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 1 x 16 GB
Memory slots: 4x DIMM
Memory clock speed: 5600 MHz
Storage
Total storage capacity: 512 GB
Storage media: SSD
Optical drive type: No
Total SSDs capacity: 512 GB
Number of SSDs installed: 1
SSD capacity: 512 GB
SSD interface: PCI Express 4.0
NVMe: Yes
SSD form factor: M.2
Card reader integrated: No
Graphics
Discrete graphics card: No
On-board graphics card: Yes
Discrete graphics card model: Not available
On-board GPU manufacturer: Intel
On-board graphics card family: Intel Graphics
On-board graphics card model: Intel Graphics
Network
Ethernet LAN: Yes
Ethernet LAN data rates: 100,1000 Mbit/s
Wi-Fi: No
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI ports quantity: 1
HDMI version: 2.1
DisplayPorts quantity: 2
Ethernet LAN (RJ-45) ports: 1
Line-out: Yes
Combo headphone/mic port: Yes
Design
Chassis type: SFF
Colour name: Black
Volume: 8.2 L
Cable lock slot: Yes
Cable lock slot type: Kensington
Product colour: Black
Performance
Motherboard chipset: Intel Q870
Audio chip: Realtek ALC623-CG
Audio system: High Definition Audio
Number of speakers: 1
Trusted Platform Module (TPM): Yes
Product type: PC
Software
Operating system architecture: 64-bit
Operating system language: German
Operating system installed: Windows 11 Pro
Power
Power supply: 260 W
Power supply input voltage: 100 – 240 V
Power supply input frequency: 50/60 Hz
Certificates
Certification: ENERGY STAR,TCO,RoHS
Weight & dimensions
Width: 92.5 mm
Depth: 299.7 mm
Height: 339.5 mm
Weight: 5.1 kg
Packaging content
Mouse included: Yes
Mouse connectivity: Wired
Keyboard included: Yes
Keyboard connectivity: Wired
Display
Display included: No
