Lanberg DSP1-1008. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 4000 entries, Switching capacity: 16 Gbit/s. Networking standards: IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. DC input voltage: 5 V
Switch is an ideal solution for domestic use due to its modest size and silent passive cooling. On top of that, black color and elegant slim case fits to almost any interior. Moreover, device is suitable for office applications, including SOHO and SMB. Lanberg switch boasts adequate performance, meeting the requirements established by users in the switch segment.
Automatic recognition and adaptation to the type of connected network cable (solid or strand) feature eliminates the requirement to use only one type of Ethernet cabling, as well as a need for uplink ports, allowing simultaneous reduction of unnecessary costs. The switch supports Half-Duplex and Full-Duplex mode for inter-device connections. Flow control feature allows data flow management, thus avoiding any data transmission blocks on the port when one of the receiving devices is unable to receive enough data.
Lanberg desktop switch guarantees a combination of high-quality, automation and a range of features ensuring stable device operation without any excessive user intervention.
Product characteristics and features:
– 8 x RJ-45 10/100/1000 Mbps ports with automatic connection negotiation,
– Plug-and-play support – product does not require any additional configuration,
– MDI / MDIX support, MAC-learning, MAC-aging,
– Flow control function: Back Pressure @ Half-Duplex and IEEE 802.3x @ Full-Duplex,
– Topology: Star,
– Protocol: CSMA / CD,
– MAC address table support: 4K,
– Switching bandwidth: 16 Gbps,
– Passive cooling for silent switch operation,
– Mounting holes for wall installation.
Interface:
– Power supply: External (AC: 100-240 V, 50/60 Hz, 0.3 A; DC: 5 V, 1.0 A)
– Power consumption: Max. 2.15 W,
– LEDs indicating PSU operation: Power, LAN ports (Link / ACT),
– Dimensions: 124 x 59 x 23 mm.
Switch type: Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
Networking standards: IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Feature: Full duplex
Feature: Half duplex
Feature: Flow control support
Feature: MAC address auto-learning supported
Feature: MAC address auto-aging supported
Data transmission
Switching capacity: 16 Gbit/s
MAC address table: 4000 entries
Packet buffer memory: 0.7 MB
Design
Product colour: Black, Grey
Housing material: Plastic
LED indicators: Yes
Power
AC input voltage: 100 – 240 V
AC input frequency: 50 – 60 Hz
DC input voltage: 5 V
Input current: 0.3 A
Power consumption (typical): 2.15 W
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Operating relative humidity (H-H): 10 – 90%
Weight & dimensions
Width: 59 mm
Depth: 124 mm
Height: 23 mm
Weight: 150 g
