Intel Core Ultra 5 245KF. Processor family: Intel Core Ultra 5, Processor socket: LGA 1851 (Socket V1), Package type: Tray. Neural processor unit (NPU): Intel AI Boost, AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN, Total processor performance up to: 22 TOPs. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR5-SDRAM. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express slots version: 4.0, 5.0. L2 cache: 26624 KB, Maximum internal memory: 192 GB
Processor
Processor manufacturer: Intel
Processor generation: Intel Core Ultra (Series 2)
Processor model: 245KF
Processor family: Intel Core Ultra 5
Processor cores: 14
Processor socket: LGA 1851 (Socket V1)
Processor operating modes: 64-bit
Performance cores: 6
Efficient cores: 8
Processor boost frequency: 5.2 GHz
Performance-core boost frequency: 5.2 GHz
Performance-core base frequency: 4.2 GHz
Efficient-core boost frequency: 4.6 GHz
Efficient-core base frequency: 3.6 GHz
Processor cache: 24 MB
Processor cache type: Smart Cache
Package type: Tray
Cooler included: No
Processor base power: 125 W
Maximum turbo power: 159 W
AI software frameworks supported by CPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Stepping: B0
Maximum number of DMI lanes: 8
Processor codename: Arrow Lake
Processor ARK ID: 241066
Neural processor unit (NPU)
Neural processor unit (NPU): Intel AI Boost
Sparsity support: Yes
Windows Studio effects support: Yes
AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to: 22 TOPs
NPU performance up to: 13 TOPs
Memory
Maximum internal memory supported by processor: 192 GB
Memory types supported by processor: DDR5-SDRAM
Memory clock speeds supported by processor: 6400 MHz
Memory channels: Dual-channel
Graphics
On-board graphics card: No
Discrete graphics card: No
On-board graphics card model: Not available
Discrete graphics card model: Not available
Features
Execute Disable Bit: Yes
Idle States: Yes
Thermal Monitoring Technologies: Yes
Market segment: Desktop
Use conditions: PC/Client/Tablet
Maximum number of PCI Express lanes: 24
PCI Express slots version: 4.0, 5.0
Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
Scalability: 1S
Embedded options available: No
Thermal solution specification: PCG 2020A
Direct Media Interface (DMI) Revision: 4.0
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): 740.17B1
Processor special features
Intel® Turbo Boost Technology: 2.0
Intel® AES New Instructions (Intel® AES-NI): Yes
Enhanced Intel SpeedStep Technology: Yes
Intel Trusted Execution Technology: Yes
Intel® Speed Shift Technology: Yes
Intel® Thunderbolt 4: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel® Thread Director: Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel® Secure Key: Yes
Intel® OS Guard: Yes
Intel 64: Yes
Intel Virtualization Technology (VT-x): Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel® Boot Guard: Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel® Volume Management Device (VMD): Yes
Mode-based Execute Control (MBE): Yes
Intel® Standard Manageability (ISM): Yes
Operational conditions
Maximum operating temperature: 105 °C
Logistics data
Harmonized System (HS) code: 8542310050
Technical details
Launch date: Q4’24
Status: Launched
Memory speed (max): 6400 MHz
Other features
L2 cache: 26624 KB
Maximum internal memory: 192 GB
Processor manufacturer: Intel
Processor generation: Intel Core Ultra (Series 2)
Processor model: 245KF
Processor family: Intel Core Ultra 5
Processor cores: 14
Processor socket: LGA 1851 (Socket V1)
Processor operating modes: 64-bit
Performance cores: 6
Efficient cores: 8
Processor boost frequency: 5.2 GHz
Performance-core boost frequency: 5.2 GHz
Performance-core base frequency: 4.2 GHz
Efficient-core boost frequency: 4.6 GHz
Efficient-core base frequency: 3.6 GHz
Processor cache: 24 MB
Processor cache type: Smart Cache
Package type: Tray
Cooler included: No
Processor base power: 125 W
Maximum turbo power: 159 W
AI software frameworks supported by CPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Stepping: B0
Maximum number of DMI lanes: 8
Processor codename: Arrow Lake
Processor ARK ID: 241066
Neural processor unit (NPU)
Neural processor unit (NPU): Intel AI Boost
Sparsity support: Yes
Windows Studio effects support: Yes
AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to: 22 TOPs
NPU performance up to: 13 TOPs
Memory
Maximum internal memory supported by processor: 192 GB
Memory types supported by processor: DDR5-SDRAM
Memory clock speeds supported by processor: 6400 MHz
Memory channels: Dual-channel
Graphics
On-board graphics card: No
Discrete graphics card: No
On-board graphics card model: Not available
Discrete graphics card model: Not available
Features
Execute Disable Bit: Yes
Idle States: Yes
Thermal Monitoring Technologies: Yes
Market segment: Desktop
Use conditions: PC/Client/Tablet
Maximum number of PCI Express lanes: 24
PCI Express slots version: 4.0, 5.0
Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
Scalability: 1S
Embedded options available: No
Thermal solution specification: PCG 2020A
Direct Media Interface (DMI) Revision: 4.0
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): 740.17B1
Processor special features
Intel® Turbo Boost Technology: 2.0
Intel® AES New Instructions (Intel® AES-NI): Yes
Enhanced Intel SpeedStep Technology: Yes
Intel Trusted Execution Technology: Yes
Intel® Speed Shift Technology: Yes
Intel® Thunderbolt 4: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel® Thread Director: Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel® Secure Key: Yes
Intel® OS Guard: Yes
Intel 64: Yes
Intel Virtualization Technology (VT-x): Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel® Boot Guard: Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel® Volume Management Device (VMD): Yes
Mode-based Execute Control (MBE): Yes
Intel® Standard Manageability (ISM): Yes
Operational conditions
Maximum operating temperature: 105 °C
Logistics data
Harmonized System (HS) code: 8542310050
Technical details
Launch date: Q4’24
Status: Launched
Memory speed (max): 6400 MHz
Other features
L2 cache: 26624 KB
Maximum internal memory: 192 GB
