Intel Core i9-14900KS. Processor family: Intel® Core™ i9, Processor socket: LGA 1700, Package type: Box. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. On-board graphics card model: Intel UHD Graphics 770, On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1, On-board graphics card base frequency: 300 MHz. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express slots version: 4.0, 5.0. Intel® Turbo Boost Max Technology 3.0 frequency: 5.9 GHz, Intel® Thermal Velocity Boost Frequency: 6.2 GHz
Processor
Processor manufacturer: Intel
Processor generation: Intel® Core™ i9 (14th gen)
Processor model: i9-14900KS
Processor family: Intel® Core™ i9
Processor cores: 24
Processor socket: LGA 1700
Processor threads: 32
Processor operating modes: 64-bit
Performance cores: 8
Efficient cores: 16
Processor boost frequency: 6.2 GHz
Performance-core boost frequency: 5.7 GHz
Performance-core base frequency: 3.2 GHz
Efficient-core boost frequency: 4.5 GHz
Efficient-core base frequency: 2.4 GHz
Processor cache: 36 MB
Processor cache type: Smart Cache
Package type: Box
Processor base power: 150 W
Maximum turbo power: 253 W
Stepping: B0
Maximum number of DMI lanes: 8
Memory bandwidth supported by processor (max): 89.6 GB/s
Processor codename: Raptor Lake
Processor ARK ID: 237504
Memory
Maximum internal memory supported by processor: 192 GB
Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
Memory channels: Dual-channel
Feature: ECC
Feature: Non-ECC
Memory bandwidth (max): 89.6 GB/s
Graphics
Feature: On-board graphics card
On-board graphics card model: Intel UHD Graphics 770
On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card base frequency: 300 MHz
On-board graphics card dynamic frequency (max): 1650 MHz
Number of displays supported (on-board graphics): 4
On-board graphics card DirectX version: 12.0
On-board graphics card OpenGL version: 4.5
On-board graphics card maximum resolution (DisplayPort): 7680 x 4320 pixels
On-board graphics card maximum resolution (eDP – Integrated Flat Panel): 5120 x 3200 pixels
On-board graphics card maximum resolution (HDMI): 4096 x 2160 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
On-board graphics card refresh rate at maximum resolution (eDP – Integrated Flat Panel): 120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI): 60 Hz
On-board graphics card ID: 0xA780
Discrete graphics card model: Not available
Number of execution units: 32
Multi-Format Codec Engines: 2
Features
Feature: Execute Disable Bit
Feature: Idle States
Feature: Thermal Monitoring Technologies
Market segment: Desktop
Use conditions: PC/Client/Tablet
Maximum number of PCI Express lanes: 20
PCI Express slots version: 4.0, 5.0
PCI Express configurations: 1×16+1×4, 2×8+1×4
Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
Scalability: 1S
CPU configuration (max): 1
Direct Media Interface (DMI) Revision: 4.0
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): 740.17B1
Processor special features
Feature: Intel® Hyper Threading Technology (Intel® HT Technology)
Intel® Turbo Boost Technology: 2.0
Feature: Intel® Quick Sync Video Technology
Feature: Intel® Clear Video HD Technology (Intel® CVT HD)
Feature: Intel® AES New Instructions (Intel® AES-NI)
Feature: Enhanced Intel SpeedStep Technology
Feature: Intel Trusted Execution Technology
Feature: Intel® Speed Shift Technology
Feature: Intel® Thermal Velocity Boost
Feature: Intel® Adaptive Boost Technology
Intel® Turbo Boost Max Technology 3.0 frequency: 5.9 GHz
Feature: Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Intel® Thermal Velocity Boost Frequency: 6.2 GHz
Feature: Intel® Control-flow Enforcement Technology (CET)
Feature: Intel® Thread Director
Feature: Intel VT-x with Extended Page Tables (EPT)
Feature: Intel® Secure Key
Feature: Intel® Active Management Technology (Intel® AMT)
Feature: Intel® OS Guard
Feature: Intel 64
Feature: Intel Virtualization Technology (VT-x)
Feature: Intel Virtualization Technology for Directed I/O (VT-d)
Feature: Intel Turbo Boost Max Technology 3.0
Feature: Intel® Boot Guard
Feature: Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Feature: Intel® Volume Management Device (VMD)
Feature: Mode-based Execute Control (MBE)
Feature: Intel® Standard Manageability (ISM)
Feature: Intel® One-Click Recovery
Feature: Intel® Remote Platform Erase (RPE)
Feature: Intel® Virtualization Technology with Redirect Protection (VT-rp)
Feature: Intel vPro® Enterprise Platform Eligibility
Feature: Intel® Threat Detection Technology (TDT)
Feature: Intel® Hardware Shield Eligibility
Feature: Intel® Total Memory Encryption – Multi Key
Feature: Intel vPro® Essentials Platform Eligibility
Operational conditions
Tjunction: 100 °C
Technical details
OpenCL version: 3.0
Launch date: Q1’24
Status: Launched
Logistics data
Harmonized System (HS) code: 8542310001
Weight & dimensions
Processor package size: 45 x 37.5 mm
Other features
L2 cache: 32768 KB
Maximum internal memory: 192 GB
Graphics output: eDP 1.4b, DP 1.4a, HDMI 2.1
Processor manufacturer: Intel
Processor generation: Intel® Core™ i9 (14th gen)
Processor model: i9-14900KS
Processor family: Intel® Core™ i9
Processor cores: 24
Processor socket: LGA 1700
Processor threads: 32
Processor operating modes: 64-bit
Performance cores: 8
Efficient cores: 16
Processor boost frequency: 6.2 GHz
Performance-core boost frequency: 5.7 GHz
Performance-core base frequency: 3.2 GHz
Efficient-core boost frequency: 4.5 GHz
Efficient-core base frequency: 2.4 GHz
Processor cache: 36 MB
Processor cache type: Smart Cache
Package type: Box
Processor base power: 150 W
Maximum turbo power: 253 W
Stepping: B0
Maximum number of DMI lanes: 8
Memory bandwidth supported by processor (max): 89.6 GB/s
Processor codename: Raptor Lake
Processor ARK ID: 237504
Memory
Maximum internal memory supported by processor: 192 GB
Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
Memory channels: Dual-channel
Feature: ECC
Feature: Non-ECC
Memory bandwidth (max): 89.6 GB/s
Graphics
Feature: On-board graphics card
On-board graphics card model: Intel UHD Graphics 770
On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card base frequency: 300 MHz
On-board graphics card dynamic frequency (max): 1650 MHz
Number of displays supported (on-board graphics): 4
On-board graphics card DirectX version: 12.0
On-board graphics card OpenGL version: 4.5
On-board graphics card maximum resolution (DisplayPort): 7680 x 4320 pixels
On-board graphics card maximum resolution (eDP – Integrated Flat Panel): 5120 x 3200 pixels
On-board graphics card maximum resolution (HDMI): 4096 x 2160 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
On-board graphics card refresh rate at maximum resolution (eDP – Integrated Flat Panel): 120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI): 60 Hz
On-board graphics card ID: 0xA780
Discrete graphics card model: Not available
Number of execution units: 32
Multi-Format Codec Engines: 2
Features
Feature: Execute Disable Bit
Feature: Idle States
Feature: Thermal Monitoring Technologies
Market segment: Desktop
Use conditions: PC/Client/Tablet
Maximum number of PCI Express lanes: 20
PCI Express slots version: 4.0, 5.0
PCI Express configurations: 1×16+1×4, 2×8+1×4
Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
Scalability: 1S
CPU configuration (max): 1
Direct Media Interface (DMI) Revision: 4.0
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): 740.17B1
Processor special features
Feature: Intel® Hyper Threading Technology (Intel® HT Technology)
Intel® Turbo Boost Technology: 2.0
Feature: Intel® Quick Sync Video Technology
Feature: Intel® Clear Video HD Technology (Intel® CVT HD)
Feature: Intel® AES New Instructions (Intel® AES-NI)
Feature: Enhanced Intel SpeedStep Technology
Feature: Intel Trusted Execution Technology
Feature: Intel® Speed Shift Technology
Feature: Intel® Thermal Velocity Boost
Feature: Intel® Adaptive Boost Technology
Intel® Turbo Boost Max Technology 3.0 frequency: 5.9 GHz
Feature: Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Intel® Thermal Velocity Boost Frequency: 6.2 GHz
Feature: Intel® Control-flow Enforcement Technology (CET)
Feature: Intel® Thread Director
Feature: Intel VT-x with Extended Page Tables (EPT)
Feature: Intel® Secure Key
Feature: Intel® Active Management Technology (Intel® AMT)
Feature: Intel® OS Guard
Feature: Intel 64
Feature: Intel Virtualization Technology (VT-x)
Feature: Intel Virtualization Technology for Directed I/O (VT-d)
Feature: Intel Turbo Boost Max Technology 3.0
Feature: Intel® Boot Guard
Feature: Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Feature: Intel® Volume Management Device (VMD)
Feature: Mode-based Execute Control (MBE)
Feature: Intel® Standard Manageability (ISM)
Feature: Intel® One-Click Recovery
Feature: Intel® Remote Platform Erase (RPE)
Feature: Intel® Virtualization Technology with Redirect Protection (VT-rp)
Feature: Intel vPro® Enterprise Platform Eligibility
Feature: Intel® Threat Detection Technology (TDT)
Feature: Intel® Hardware Shield Eligibility
Feature: Intel® Total Memory Encryption – Multi Key
Feature: Intel vPro® Essentials Platform Eligibility
Operational conditions
Tjunction: 100 °C
Technical details
OpenCL version: 3.0
Launch date: Q1’24
Status: Launched
Logistics data
Harmonized System (HS) code: 8542310001
Weight & dimensions
Processor package size: 45 x 37.5 mm
Other features
L2 cache: 32768 KB
Maximum internal memory: 192 GB
Graphics output: eDP 1.4b, DP 1.4a, HDMI 2.1
