Intel Core i5-14600KF. Processor family: Intel® Core™ i5, Processor socket: LGA 1700, Package type: Tray. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express slots version: 4.0, 5.0. Processor package size: 45 x 37.5 mm. L2 cache: 20480 KB, Maximum internal memory: 192 GB
Processor
Processor manufacturer: Intel
Processor generation: Intel® Core™ i5 (14th gen)
Processor model: i5-14600KF
Processor family: Intel® Core™ i5
Processor cores: 14
Processor socket: LGA 1700
Processor threads: 20
Processor operating modes: 64-bit
Performance cores: 6
Efficient cores: 8
Processor boost frequency: 5.3 GHz
Performance-core boost frequency: 5.3 GHz
Performance-core base frequency: 3.5 GHz
Efficient-core boost frequency: 4 GHz
Efficient-core base frequency: 2.6 GHz
Processor cache: 24 MB
Processor cache type: Smart Cache
Package type: Tray
Processor base power: 125 W
Maximum turbo power: 181 W
Stepping: B0
Maximum number of DMI lanes: 8
Memory bandwidth supported by processor (max): 89.6 GB/s
Processor codename: Raptor Lake
Processor ARK ID: 236778
Memory
Maximum internal memory supported by processor: 192 GB
Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
Memory channels: Dual-channel
Memory bandwidth (max): 89.6 GB/s
Graphics
On-board graphics card model: Not available
Discrete graphics card model: Not available
Features
Feature: Execute Disable Bit
Feature: Idle States
Feature: Thermal Monitoring Technologies
Market segment: Desktop
Use conditions: PC/Client/Tablet
Maximum number of PCI Express lanes: 20
PCI Express slots version: 4.0, 5.0
PCI Express configurations: 1×16+1×4, 2×8+1×4
Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
Scalability: 1S
CPU configuration (max): 1
Thermal solution specification: PCG 2020A
Direct Media Interface (DMI) Revision: 4.0
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): 740.17B1
Processor special features
Feature: Intel® Hyper Threading Technology (Intel® HT Technology)
Intel® Turbo Boost Technology: 2.0
Feature: Intel® AES New Instructions (Intel® AES-NI)
Feature: Enhanced Intel SpeedStep Technology
Feature: Intel® Speed Shift Technology
Feature: Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Feature: Intel® Control-flow Enforcement Technology (CET)
Feature: Intel® Thread Director
Feature: Intel VT-x with Extended Page Tables (EPT)
Feature: Intel® Secure Key
Feature: Intel® OS Guard
Feature: Intel 64
Feature: Intel Virtualization Technology (VT-x)
Feature: Intel Virtualization Technology for Directed I/O (VT-d)
Feature: Intel® Boot Guard
Feature: Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Feature: Intel® Volume Management Device (VMD)
Feature: Mode-based Execute Control (MBE)
Feature: Intel® Standard Manageability (ISM)
Operational conditions
Tjunction: 100 °C
Logistics data
Harmonized System (HS) code: 8542310001
Technical details
Launch date: Q4’23
Status: Launched
Weight & dimensions
Processor package size: 45 x 37.5 mm
Other features
L2 cache: 20480 KB
Maximum internal memory: 192 GB
Processor manufacturer: Intel
Processor generation: Intel® Core™ i5 (14th gen)
Processor model: i5-14600KF
Processor family: Intel® Core™ i5
Processor cores: 14
Processor socket: LGA 1700
Processor threads: 20
Processor operating modes: 64-bit
Performance cores: 6
Efficient cores: 8
Processor boost frequency: 5.3 GHz
Performance-core boost frequency: 5.3 GHz
Performance-core base frequency: 3.5 GHz
Efficient-core boost frequency: 4 GHz
Efficient-core base frequency: 2.6 GHz
Processor cache: 24 MB
Processor cache type: Smart Cache
Package type: Tray
Processor base power: 125 W
Maximum turbo power: 181 W
Stepping: B0
Maximum number of DMI lanes: 8
Memory bandwidth supported by processor (max): 89.6 GB/s
Processor codename: Raptor Lake
Processor ARK ID: 236778
Memory
Maximum internal memory supported by processor: 192 GB
Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
Memory channels: Dual-channel
Memory bandwidth (max): 89.6 GB/s
Graphics
On-board graphics card model: Not available
Discrete graphics card model: Not available
Features
Feature: Execute Disable Bit
Feature: Idle States
Feature: Thermal Monitoring Technologies
Market segment: Desktop
Use conditions: PC/Client/Tablet
Maximum number of PCI Express lanes: 20
PCI Express slots version: 4.0, 5.0
PCI Express configurations: 1×16+1×4, 2×8+1×4
Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
Scalability: 1S
CPU configuration (max): 1
Thermal solution specification: PCG 2020A
Direct Media Interface (DMI) Revision: 4.0
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): 740.17B1
Processor special features
Feature: Intel® Hyper Threading Technology (Intel® HT Technology)
Intel® Turbo Boost Technology: 2.0
Feature: Intel® AES New Instructions (Intel® AES-NI)
Feature: Enhanced Intel SpeedStep Technology
Feature: Intel® Speed Shift Technology
Feature: Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Feature: Intel® Control-flow Enforcement Technology (CET)
Feature: Intel® Thread Director
Feature: Intel VT-x with Extended Page Tables (EPT)
Feature: Intel® Secure Key
Feature: Intel® OS Guard
Feature: Intel 64
Feature: Intel Virtualization Technology (VT-x)
Feature: Intel Virtualization Technology for Directed I/O (VT-d)
Feature: Intel® Boot Guard
Feature: Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Feature: Intel® Volume Management Device (VMD)
Feature: Mode-based Execute Control (MBE)
Feature: Intel® Standard Manageability (ISM)
Operational conditions
Tjunction: 100 °C
Logistics data
Harmonized System (HS) code: 8542310001
Technical details
Launch date: Q4’23
Status: Launched
Weight & dimensions
Processor package size: 45 x 37.5 mm
Other features
L2 cache: 20480 KB
Maximum internal memory: 192 GB
