Intel Core i3-14100F. Processor family: Intel® Core™ i3, Processor socket: LGA 1700, Package type: Tray. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express slots version: 4.0, 5.0. Processor package size: 45 x 37.5 mm. L2 cache: 5120 KB, Maximum internal memory: 192 GB
Processor
Processor manufacturer: Intel
Processor generation: Intel® Core™ i3 (14th gen)
Processor model: i3-14100F
Processor family: Intel® Core™ i3
Processor cores: 4
Processor socket: LGA 1700
Processor threads: 8
Processor operating modes: 64-bit
Performance cores: 4
Processor boost frequency: 4.7 GHz
Performance-core boost frequency: 4.7 GHz
Performance-core base frequency: 3.5 GHz
Processor cache: 12 MB
Processor cache type: Smart Cache
Package type: Tray
Processor base power: 58 W
Maximum turbo power: 110 W
Stepping: H0
Maximum number of DMI lanes: 8
Memory bandwidth supported by processor (max): 76.8 GB/s
Processor codename: Raptor Lake
Processor ARK ID: 236786
Memory
Maximum internal memory supported by processor: 192 GB
Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
Memory channels: Dual-channel
Memory bandwidth (max): 76.8 GB/s
Graphics
On-board graphics card: No
Discrete graphics card: No
On-board graphics card model: Not available
Discrete graphics card model: Not available
Features
Execute Disable Bit: Yes
Idle States: Yes
Thermal Monitoring Technologies: Yes
Market segment: Desktop
Use conditions: PC/Client/Tablet
Maximum number of PCI Express lanes: 20
PCI Express slots version: 4.0, 5.0
PCI Express configurations: 1×16+1×4, 2×8+1×4
Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
Scalability: 1S
CPU configuration (max): 1
Embedded options available: No
Direct Media Interface (DMI) Revision: 4.0
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): 740.17B1
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Intel® Turbo Boost Technology: 2.0
Intel® AES New Instructions (Intel® AES-NI): Yes
Enhanced Intel SpeedStep Technology: Yes
Intel® Speed Shift Technology: Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel® Secure Key: Yes
Intel® OS Guard: Yes
Intel 64: Yes
Intel Virtualization Technology (VT-x): Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel® Boot Guard: Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel® Volume Management Device (VMD): Yes
Mode-based Execute Control (MBE): Yes
Intel® Standard Manageability (ISM): Yes
Operational conditions
Tjunction: 100 °C
Logistics data
Harmonized System (HS) code: 8542310001
Technical details
Launch date: Q1’24
Status: Launched
Weight & dimensions
Processor package size: 45 x 37.5 mm
Other features
L2 cache: 5120 KB
Maximum internal memory: 192 GB
Processor manufacturer: Intel
Processor generation: Intel® Core™ i3 (14th gen)
Processor model: i3-14100F
Processor family: Intel® Core™ i3
Processor cores: 4
Processor socket: LGA 1700
Processor threads: 8
Processor operating modes: 64-bit
Performance cores: 4
Processor boost frequency: 4.7 GHz
Performance-core boost frequency: 4.7 GHz
Performance-core base frequency: 3.5 GHz
Processor cache: 12 MB
Processor cache type: Smart Cache
Package type: Tray
Processor base power: 58 W
Maximum turbo power: 110 W
Stepping: H0
Maximum number of DMI lanes: 8
Memory bandwidth supported by processor (max): 76.8 GB/s
Processor codename: Raptor Lake
Processor ARK ID: 236786
Memory
Maximum internal memory supported by processor: 192 GB
Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
Memory channels: Dual-channel
Memory bandwidth (max): 76.8 GB/s
Graphics
On-board graphics card: No
Discrete graphics card: No
On-board graphics card model: Not available
Discrete graphics card model: Not available
Features
Execute Disable Bit: Yes
Idle States: Yes
Thermal Monitoring Technologies: Yes
Market segment: Desktop
Use conditions: PC/Client/Tablet
Maximum number of PCI Express lanes: 20
PCI Express slots version: 4.0, 5.0
PCI Express configurations: 1×16+1×4, 2×8+1×4
Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
Scalability: 1S
CPU configuration (max): 1
Embedded options available: No
Direct Media Interface (DMI) Revision: 4.0
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): 740.17B1
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Intel® Turbo Boost Technology: 2.0
Intel® AES New Instructions (Intel® AES-NI): Yes
Enhanced Intel SpeedStep Technology: Yes
Intel® Speed Shift Technology: Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel® Secure Key: Yes
Intel® OS Guard: Yes
Intel 64: Yes
Intel Virtualization Technology (VT-x): Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel® Boot Guard: Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel® Volume Management Device (VMD): Yes
Mode-based Execute Control (MBE): Yes
Intel® Standard Manageability (ISM): Yes
Operational conditions
Tjunction: 100 °C
Logistics data
Harmonized System (HS) code: 8542310001
Technical details
Launch date: Q1’24
Status: Launched
Weight & dimensions
Processor package size: 45 x 37.5 mm
Other features
L2 cache: 5120 KB
Maximum internal memory: 192 GB
