Intel Core i3-14100T processor

Processor
Processor manufacturer: Intel
Processor generation: Intel® Core™ i3 (14th gen)
Processor model: i3-14100T
Processor family: Intel® Core™ i3
Processor cores: 4
Processor socket: LGA 1700
Processor threads: 8
Processor operating modes: 64-bit
Performance cores: 4
Processor boost frequency: 4.4 GHz
Performance-core boost frequency: 4.4 GHz
Performance-core base frequency: 2.7 GHz
Processor cache: 12 MB
Processor cache type: Smart Cache
Package type: Tray
Processor base power: 35 W
Maximum turbo power: 69 W
Stepping: H0
Maximum number of DMI lanes: 8
Memory bandwidth supported by processor (max): 76.8 GB/s
Processor codename: Raptor Lake
Processor ARK ID: 236775
Memory
Maximum internal memory supported by processor: 192 GB
Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
Memory channels: Dual-channel
Memory bandwidth (max): 76.8 GB/s
Graphics
Feature: On-board graphics card
On-board graphics card model: Intel UHD Graphics 730
On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card dynamic frequency (max): 1500 MHz
Number of displays supported (on-board graphics): 4
On-board graphics card DirectX version: 12.0
On-board graphics card OpenGL version: 4.5
On-board graphics card maximum resolution (DisplayPort): 7680 x 4320 pixels
On-board graphics card maximum resolution (eDP – Integrated Flat Panel): 5120 x 3200 pixels
On-board graphics card maximum resolution (HDMI): 4096 x 2160 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
On-board graphics card refresh rate at maximum resolution (eDP – Integrated Flat Panel): 120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI): 60 Hz
On-board graphics card ID: 0x4692
Discrete graphics card model: Not available
Number of execution units: 24
Multi-Format Codec Engines: 1
Features
Feature: Execute Disable Bit
Feature: Idle States
Feature: Thermal Monitoring Technologies
Market segment: Desktop
Use conditions: PC/Client/Tablet
Maximum number of PCI Express lanes: 20
PCI Express slots version: 4.0, 5.0
PCI Express configurations: 1×16+1×4, 2×8+1×4
Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
Scalability: 1S
CPU configuration (max): 1
Feature: Embedded options available
Direct Media Interface (DMI) Revision: 4.0
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): 740.17B1
Processor special features
Feature: Intel® Hyper Threading Technology (Intel® HT Technology)
Intel® Turbo Boost Technology: 2.0
Feature: Intel® Quick Sync Video Technology
Feature: Intel® Clear Video HD Technology (Intel® CVT HD)
Feature: Intel® AES New Instructions (Intel® AES-NI)
Feature: Enhanced Intel SpeedStep Technology
Feature: Intel® Speed Shift Technology
Feature: Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Feature: Intel® Control-flow Enforcement Technology (CET)
Feature: Intel VT-x with Extended Page Tables (EPT)
Feature: Intel® Secure Key
Feature: Intel® OS Guard
Feature: Intel 64
Feature: Intel Virtualization Technology (VT-x)
Feature: Intel Virtualization Technology for Directed I/O (VT-d)
Feature: Intel® Boot Guard
Feature: Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Feature: Intel® Volume Management Device (VMD)
Feature: Mode-based Execute Control (MBE)
Feature: Intel® Standard Manageability (ISM)
Operational conditions
Tjunction: 100 °C
Technical details
OpenCL version: 3.0
Launch date: Q1’24
Status: Launched
Logistics data
Harmonized System (HS) code: 8542310001
Weight & dimensions
Processor package size: 45 x 37.5 mm
Other features
L2 cache: 5120 KB
Maximum internal memory: 192 GB
Graphics output: eDP 1.4b, DP 1.4a, HDMI 2.1
