iiyama ProLite TF1934MC-B2X. Display diagonal: 48.3 cm (19"), Display resolution: 1280 x 1024 pixels, Display technology: LED, Response time: 14 ms, Native aspect ratio: 5:4, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black
The ProLite TF1934MC-B2X 19″ multi touch screen is based on projective capacitive technology which thanks to a glass overlay covering the screen guarantees high durability, scratch-resistance and perfect picture performance. The IPS matrix guarantees high performance with accurate and consistent colour reproduction, and wide viewing angles. The touch function remains unaffected even if the glass is scratched. The screen is IP65 rated which means it is dust and water resistant. For ease of installation in any environment the ProLite TF1934MC-B2X comes equipped with external mounting brackets making it an ideal solution for kiosk integrators and Instore Retail.
Display
Display diagonal: 48.3 cm (19″)
Display resolution: 1280 x 1024 pixels
Native aspect ratio: 5:4
Display technology: LED
Panel type: IPS
Feature: Touchscreen
Touchscreen technology: Projected capacitive system
Touch technology: Multi-touch
Display brightness: 225 cd/m²
Response time: 14 ms
Screen shape: Flat
Aspect ratio: 5:4
Contrast ratio (typical): 1000:1
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Display number of colours: 16.78 million colours
Pixel pitch: 0.294 x 0.294 mm
Viewable size diagonal: 48 cm
Digital horizontal frequency: 31.4 – 80 kHz
Digital vertical frequency: 56 – 75 Hz
Display diagonal (metric): 48 cm
Feature: Separate H/V sync
Performance
Windows operating systems supported: Yes
Number of simultaneous touchpoints (Windows 7): 10
Multimedia
Megapixel (approx.): 1.3 MP
Design
Product colour: Black
Ports & interfaces
Number of upstream ports: 1
VGA (D-Sub) ports quantity: 1
Feature: DVI port
DVI-D ports quantity: 1
Ergonomics
Feature: VESA mounting
Panel mounting interface: 100 x 100 mm
Feature: Wall mountable
Feature: Cable lock slot
On Screen Display (OSD) languages: Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese
Number of OSD languages: 8
Feature: Plug and Play
Power
Power consumption (typical): 20 W
Power consumption (standby): 2 W
Power supply type: AC/DC
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Storage temperature (T-T): -20 – 60 °C
Operating relative humidity (H-H): 20 – 80%
Storage relative humidity (H-H): 10 – 90%
Weight & dimensions
Width (without stand): 416 mm
Depth (without stand): 46.5 mm
Height (without stand): 344.5 mm
Weight (without stand): 4.5 kg
Packaging content
Cables included: AC, DVI, USB, VGA
Feature: Quick start guide
Other features
International Protection (IP) code: IP65
Display viewable area (HxV): 376.5 x 301.1 mm
Feature: Power management
Supplied AC adapter type: AC
Certification: CE, CB, TÜV-Bauart, CU, cULus
Logistics data
Harmonized System (HS) code: 85285210
Display diagonal: 48.3 cm (19″)
Display resolution: 1280 x 1024 pixels
Native aspect ratio: 5:4
Display technology: LED
Panel type: IPS
Feature: Touchscreen
Touchscreen technology: Projected capacitive system
Touch technology: Multi-touch
Display brightness: 225 cd/m²
Response time: 14 ms
Screen shape: Flat
Aspect ratio: 5:4
Contrast ratio (typical): 1000:1
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Display number of colours: 16.78 million colours
Pixel pitch: 0.294 x 0.294 mm
Viewable size diagonal: 48 cm
Digital horizontal frequency: 31.4 – 80 kHz
Digital vertical frequency: 56 – 75 Hz
Display diagonal (metric): 48 cm
Feature: Separate H/V sync
Performance
Windows operating systems supported: Yes
Number of simultaneous touchpoints (Windows 7): 10
Multimedia
Megapixel (approx.): 1.3 MP
Design
Product colour: Black
Ports & interfaces
Number of upstream ports: 1
VGA (D-Sub) ports quantity: 1
Feature: DVI port
DVI-D ports quantity: 1
Ergonomics
Feature: VESA mounting
Panel mounting interface: 100 x 100 mm
Feature: Wall mountable
Feature: Cable lock slot
On Screen Display (OSD) languages: Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese
Number of OSD languages: 8
Feature: Plug and Play
Power
Power consumption (typical): 20 W
Power consumption (standby): 2 W
Power supply type: AC/DC
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Storage temperature (T-T): -20 – 60 °C
Operating relative humidity (H-H): 20 – 80%
Storage relative humidity (H-H): 10 – 90%
Weight & dimensions
Width (without stand): 416 mm
Depth (without stand): 46.5 mm
Height (without stand): 344.5 mm
Weight (without stand): 4.5 kg
Packaging content
Cables included: AC, DVI, USB, VGA
Feature: Quick start guide
Other features
International Protection (IP) code: IP65
Display viewable area (HxV): 376.5 x 301.1 mm
Feature: Power management
Supplied AC adapter type: AC
Certification: CE, CB, TÜV-Bauart, CU, cULus
Logistics data
Harmonized System (HS) code: 85285210
