HPE Aruba Networking AP-567 (RW) 802.11ax Dual 2×2 Radio Integrated Directional Antennas Outdoor AP. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1774 Mbit/s. Security algorithms: WPA2, WPA3. Ethernet LAN data rates: 1000 Mbit/s. Power over Ethernet (PoE). Product colour: White
What is new supporting point:
Ready for Internet of Things (IoT) with a built-in Bluetooth 5 and 802.15.4 radio that supports Zigbee
Small form factor for flexible deployment.
Client and RF optimization to match clients with the best available access point and reduce coverage gaps
Dynamic segmentation and policy enforcement firewalls (PEFs) that automatically enforce consistent policies across all networks, keeping users and devices secure
Purpose-built to survive in the harshest outdoor environments and extreme temperatures (-40 ̊C to +55 ̊C)
Entry-level outdoor Wi-Fi 6 (802.11ax) access points that provide up to 1.49 Gbps peak aggregate data rate and are ideal for outdoor and warehouse environments
Feature: 2.4 GHz
Feature: 5 GHz
Maximum data transfer rate: 1774 Mbit/s
Maximum data transfer rate (2.4 GHz): 574 Mbit/s
Maximum data transfer rate (5 GHz): 1200 Mbit/s
Ethernet LAN data rates: 1000 Mbit/s
Frequency band: 20/40 (2.4GHz), 20/40/80 (5GHz), peak data rate 1.49 Gbps, maximum data rate 1.78 Gbps
Networking standards: IEEE 802.11ax, IEEE 802.11mc
Feature: Bluetooth
Bluetooth version: 5.0
Feature: Auto MDI/MDI-X
Feature: MIMO
MIMO type: Multi User MIMO
Spread spectrum method: DSSS, OFDM, OFDMA
Modulation: 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK
Security
Security algorithms: WPA2, WPA3
Management features
Access point management: On-premises; Public Cloud; Virtual Private Cloud (VPC); as a Service
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
USB connector type: USB Type-C
Power
Feature: Power over Ethernet (PoE)
Design
Placement: Pole, Wall
Product colour: White
Recommended usage: Outdoor
Antenna
Antenna type: Internal
Antenna direction type: Directional
Antenna features: Integrated antenna
Antenna gain level (max): 7 dBi
Performance
Compatible operating systems: HPE Aruba Networking Wireless Operating System 8 and HPE Aruba Networking Instant OS 8.7.1.0 HPE Aruba Networking Wireless Operating System 10.3.0.0
Certificates
Compliance certificates: Federal Communications Commission (FCC), ISED, CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD)
Weight & dimensions
Width: 165 mm
Depth: 130 mm
Height: 165 mm
Weight: 1.09 kg
Other features
I/O ports: E0: 10/100/1000BASE-T (RJ-45) USB-C console interface
Weight (imperial): 1.09 kg (2.4 lbs)
Operational conditions
Operating relative humidity (H-H): 5 – 95%
Operating temperature (T-T): -40 – 55 °C
Storage temperature (T-T): -40 – 70 °C
Operating altitude: 0 – 3000 m
Logistics data
Harmonized System (HS) code: 85176990
