HPE Aruba Networking 2930M 24G PoE+ 1-slot Switch. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 20. Full duplex. MAC address table: 32768 entries, Switching capacity: 128 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
What is new supporting point:
The 2930M Series is a family of layer 3 stackable switches that are easy to deploy and manage, providing scale and modularity for enterprise, SMB and branch access networks.
Simplify with Zero Touch Provisioning and cloud-based HPE Aruba Networking Central support.
Models with 24 ports of HPE Smart Rate with IEEE 802.3bz.
Scale with modular 10 chassis stacking and up to 1440W PoE.
Modular 10 GbE and 40 GbE uplinks and HPE Smart Rate multi-gigabit support.
High Power PoE models deliver up to 60W of PoE per port.
Switch type: Managed
Switch layer: L3
Feature: Quality of Service (QoS) support
Feature: Web-based management
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 20
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity: 4
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Feature: 10G support
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Feature: Full duplex
Feature: IP routing
Feature: Flow control support
Feature: Link aggregation
Feature: Rate limiting
Feature: Auto MDI/MDI-X
Feature: Spanning tree protocol
Feature: Auto-sensing
Feature: VLAN support
Data transmission
Switching capacity: 128 Gbit/s
Throughput: 95.2 Mpps
MAC address table: 32768 entries
Latency (10-100 Mbps): 11.8 µs
Latency (1 Gbps): 3.1 µs
Latency (10 Gbps): 3.4 µs
Packet buffer memory: 12.38 MB
Security
Feature: Access Control List (ACL)
Feature: IGMP snooping
Feature: SSH/SSL support
Authentication: MAC-based authentication, Web-based authentication
Multicast features
Feature: Multicast support
Design
Feature: Rack mounting
Feature: Stackable
Form factor: 1U
Product colour: Grey
Performance
Feature: Built-in processor
Processor frequency: 1016 MHz
Memory type: DDR3-SDRAM
Internal memory: 1024 MB
Power
AC input voltage: 200 – 240 V
AC input frequency: 50/60 Hz
Power consumption (typical): 680 W
Power consumption note: 2 power supplies are supported: JL086A PSU (each): 450W JL087A PSU (each): 840W
Power supply note: JL086A X372 54VDC 680W 100-240VAC Power Supply, JL087A X372 54VDC 1050W 110-240VAC Power Supply
Power over Ethernet (PoE)
Feature: Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 720 W
Other features
Latency: 1000 Mb Latency: < 3.1 μs 10 Gbps Latency: < 3.4 μs
Memory and processor: Dual Core ARM Coretex A9 @ 1016 MHz 1 GB DDR3 SDRAM Packet buffer size: 12.38 MB and 4.5 MB Ingress, 7.785 Egress 4 GB eMMC
Weight (imperial): 4.5 kg (9.92 lbs)
Dimensions (W x D x H) (imperial): 43.9 x 442.5 x 324.4 mm (1.73 x 17.4 x 12.8″)
Operational conditions
Operating temperature (T-T): 0 – 55 °C
Storage temperature (T-T): -40 – 70 °C
Operating relative humidity (H-H): 15 – 95%
Heat dissipation: 150 BTU/h
Weight & dimensions
Width: 43.9 mm
Depth: 442.5 mm
Height: 324.3 mm
Weight: 4.5 kg
Logistics data
Harmonized System (HS) code: 85176990
