Honeywell PM45 Compact. Print technology: Thermal transfer, Maximum resolution: 203 x 203 DPI, Print speed: 350 mm/sec. Connectivity technology: Wired & Wireless, Ethernet LAN, USB port. Product colour: Black
Enterprises today are facing increasing challenges on production flexibility, inventory turnover, and cost control. The Honeywell PM45 industrial printer is designed to give businesses the flexibility and precision for high-volume printing. The PM45 printer’s track-and-trace functionality is aimed at improving print efficiency and supply chain transparency within a variety of industries, including food and beverage, pharmaceuticals, manufacturing, warehouse, and distribution center management.
Built on the Honeywell print platform, the durable PM45 printer offers print speeds of up to 14 ips. With print registration of up to +/-0.5 mm, the PM45 printer can ensure high-quality prints for barcodes, texts, and images, even on small electronic components and medical device labels.
As a highly connected industrial printer, the PM45 is packed with enhanced WWAN connectivity to enable deployment with minimal limitation from site network topology. The PM45 printer’s versatility allows the user to incorporate RFID, parallel, industrial, and applicator interfaces to address unpredictable future business needs. To help your transformation to intelligent manufacturing and supply chain management, the PM45 printer supports variable network protocols and multiple print languages to enable easy integration into your system, whether it is cloud-based or on a local server.
Embedded with Honeywell’s Smart Parse software, the PM45 allows for quick position changes, sizing of objects and barcodes, or font type on labels, without the need for backend system changes or programming skills. With Honeywell’s Operational Intelligence software, users can remotely manage and monitor the PM45 printer’s diagnostics and output performance. The PM45 supports a wide range of media – including ink-in and ink-out ribbons with a 1-inch core size – enhancing the time between media resupplies.
The PM45 printer is an ideal replacement for existing Honeywell or mixed printers, especially with Honeywell’s firmware platform supporting multiple print languages. A rugged, all-metal print mechanism, easy printhead, and tool-free platen roller replacement helps minimize downtime and maintenance needs.
Print technology: Thermal transfer
Maximum resolution: 203 x 203 DPI
Number of printable dots: 8 dot
Print speed: 350 mm/sec
Printing colours: Black
Maximum printing width: 10.8 cm
Margin depth settings: Fixed
Maximum print length: 4.8 m
Paper handling
Maximum label width: 11.4 cm
Maximum roll diameter: 21.3 cm
Core diameter: 7.62 cm
Ports & interfaces
Connectivity technology: Wired & Wireless
Feature: Ethernet LAN
Feature: USB port
USB 2.0 ports quantity: 1
RS-232 ports: 1
Performance
Page description languages: DP, DPL, IPL, XML, ZPL II
Internal memory: 256 MB
Flash memory: 512 MB
Built-in barcodes: 1D, 2D
Image formats supported: BMP, GIF, PCX, PNG
Design
Product colour: Black
Feature: Built-in display
Display: LCD
Control type: Touch
Power
Power consumption (standby): 9.6 W
AC input voltage: 100 – 240 V
AC input frequency: 50 – 60 Hz
System requirements
Windows operating systems supported: Yes
Mobile operating systems supported: Android, iOS
Linux operating systems supported: Yes
Operational conditions
Operating relative humidity (H-H): 20 – 85%
Storage relative humidity (H-H): 5 – 90%
Operating temperature (T-T): 5 – 40 °C
Storage temperature (T-T): -20 – 70 °C
Weight & dimensions
Width: 253 mm
Depth: 432 mm
Height: 181 mm
Weight: 12.6 kg
Logistics data
Harmonized System (HS) code: 84433210
Technical details
Sustainability certificates: ENERGY STAR
Compliance certificates: CE, RoHS
Other features
Languages support: Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Portuguese, Russian, Thai
