GIGABYTE R113-C10-AA02. Motherboard chipset: AMD B650E, Processor socket: Socket AM5, Compatible processor series: AMD EPYC™ 4005 Series, AMD Ryzen 9000 Series. Supported memory types: DDR5-SDRAM, Memory channels: Dual-channel. Storage drive sizes supported: 2.5,M.2, Supported storage drive types: HDD & SSD, Supported storage drive interfaces: Serial ATA, PCI Express 5.0. On-board graphics card model: Aspeed AST2600. Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, LAN controller: Intel® I210-AT
AMD EPYC™ CPUs for 24×7 Business Growth and Manageability
AMD EPYC™ 4004 Series Processors were a welcome addition to the 4th Gen AMD EPYC™ processor family, and now the 4005 Series comes out of a new processor family with “Zen 5” core architecture – lowering the threshold for businesses and hosting services that have been wanting to move to a platform with a server OS and other enterprise features, yet at an optimal price point in GIGABYTE solutions. SMB and hosting services rely on server-grade reliability so they can continue running 24×7. At the same time, they need to have a higher degree of manageability than what is found at the consumer level. On top of validating, GIGABYTE provides GIGABYTE Management Console (GMC) for system management and GIGABYTE Server Management (GSM) software for monitoring multiple servers.
AMD EPYC™ 4004 Series Processors were a welcome addition to the 4th Gen AMD EPYC™ processor family, and now the 4005 Series comes out of a new processor family with “Zen 5” core architecture – lowering the threshold for businesses and hosting services that have been wanting to move to a platform with a server OS and other enterprise features, yet at an optimal price point in GIGABYTE solutions. SMB and hosting services rely on server-grade reliability so they can continue running 24×7. At the same time, they need to have a higher degree of manageability than what is found at the consumer level. On top of validating, GIGABYTE provides GIGABYTE Management Console (GMC) for system management and GIGABYTE Server Management (GSM) software for monitoring multiple servers.
Processor
Motherboard chipset: AMD B650E
Processor socket: Socket AM5
Number of processors supported: 1
Compatible processor series: AMD EPYC™ 4005 Series, AMD Ryzen 9000 Series
Memory
Number of DIMM slots: 4
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Feature: ECC
Feature: Non-ECC
Storage
Number of storage drives supported: 5
Feature: Hot-swap HDD bays
Number of 2.5″ bays: 4
Storage drive sizes supported: 2.5,M.2
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: Serial ATA, PCI Express 5.0
RAID levels: 0, 1, 10
SSD form factor: M.2
Graphics
On-board graphics card model: Aspeed AST2600
Network
Feature: Ethernet LAN
Ethernet interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
LAN controller: Intel® I210-AT
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Ethernet LAN (RJ-45) ports: 2
VGA (D-Sub) ports quantity: 1
COM ports quantity: 1
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 1
Features
Feature: Trusted Platform Module (TPM)
Compatible operating systems: Ubuntu 22.04Ubuntu 24.04; Windows Server 2022; Windows Server 2025; Windows 10 21H2; Windows 11
Design
Chassis type: Rack (1U)
Product colour: Black, Steel
LED indicators: LAN, HDD, SSD, Status
Feature: On/off switch
Feature: Reset button
Cooling type: Active
Feature: Heat sink included
Number of fans: 3 fan(s)
Fan diameter: 4 cm
Power
Power supply: 400 W
Number of main power supplies: 1
Feature: Redundant power supply (RPS) support
AC input voltage: 100 – 240 V
AC input frequency: 50/60 Hz
Input current: 3 – 6 A
DC output current (+5 V): 16 A
DC output current (+12 V): 33 A
80 PLUS certification: 80 PLUS Gold
Operational conditions
Operating temperature (T-T): 10 – 30 °C
Storage temperature (T-T): -40 – 60 °C
Operating relative humidity (H-H): 8 – 80%
Storage relative humidity (H-H): 20 – 95%
Weight & dimensions
Width: 430 mm
Depth: 393.2 mm
Height: 43.5 mm
Weight: 6.25 kg
Packaging data
Packaging content: 1 x R113-C10-AA02; 1 x CPU heatsink
Package width: 599 mm
Package depth: 535 mm
Package height: 161 mm
Package weight: 11.2 kg
