Epson TM-U220IIB (102): Serial, PS, NE sensor, EDG. Print technology: Dot matrix, Type: POS printer, Print speed: 4.7 lps. Maximum roll diameter: 8.3 cm. Connectivity technology: Wired, Serial interface type: RS-232, Interface: RS-232, Drawer kick-out. Page description languages: ESC/POS, Sound pressure level (printing): 64 dB, Mean time between failures (MTBF): 180000 h. Product colour: Dark Grey
Easy to use, compact and versatile, the TM-U220II impact receipt printer is perfect for a wide variety of applications. The increased buffer size allows more orders to be received at the same time, while the printing speed provides high-efficiency throughput.
Easy to use
The TM-U220II is a robust, high performance impact receipt printer which is exceptionally easy to use. Featuring drop-in paper load, selectable auto-cutter and clamshell covers for easy access and maintenance, the TM-U220II is very reliable and prints on plain paper in three widths.
Increased memory
An increased buffer allows more orders to be received at the same time, making it ideal for those busy environments where order success is critical. It supports more orders being received from multiple devices, which means that more tickets can be processed in a shorter time, keeping the operation flowing.
High printing speed
The TM-U220II provides high-efficiency throughput. Retailers can hand receipts to customers faster. Restaurant kitchens can receive orders quickly.
Superior versatility
The TM-U220II suits a wide range of needs and applications. Each model in the series is powerful, yet compact enough to fit in confined spaces. In addition, the wall-mounting option frees up valuable counter space in kitchens and other tight locations.
Outstanding compatibility
The TM-U220II printers are designed to be compatible with systems built around predecessor models. These systems can be upgraded simply by dropping in a TM-U220II. Moreover, since the external dimensions are nearly identical, there is no need to change the installation environment.
Distinctive sound
The distinctive printing sound of the TM-U220II makes it stand out among the soundscape of a noisy kitchen environment. This draws attention to incoming orders and reduces the customers’ waiting times.
Print speed: 4.7 lps
Character density: 16 cpi
Print technology: Dot matrix
Type: POS printer
Paper handling
Maximum roll diameter: 8.3 cm
Ports & interfaces
Feature: Serial interface
Serial interface type: RS-232
Connectivity technology: Wired
Interface: RS-232, Drawer kick-out
Features
Page description languages: ESC/POS
Sound pressure level (printing): 64 dB
Mean time between failures (MTBF): 180000 h
Feature: Cutter
Autocutter durability: 0.8 million cuts
Receive buffer: 40 KB
Design
Product colour: Dark Grey
Power
Power source type: AC
Power consumption (printing): 31 W
AC input voltage: 24 V
Operational conditions
Storage temperature (T-T): -10 – 50 °C
Operating relative humidity (H-H): 10 – 90%
Storage relative humidity (H-H): 10 – 90%
Weight & dimensions
Width: 160 mm
Depth: 248 mm
Height: 139 mm
Weight: 2.5 kg
Packaging data
Quantity per pack: 1 pc(s)
Package width: 30 mm
Package depth: 33 mm
Package height: 22 mm
Package weight: 3.84 kg
Logistics data
Products per pallet: 72 pc(s)
Products per pallet layer: 8 pc(s)
Pallet gross width: 80 cm
Pallet gross length: 120 cm
Pallet gross height: 34.8 cm
Products per pallet (UK): 108 pc(s)
Products per pallet layer (UK): 12 pc(s)
Pallet length (UK): 120 cm
Pallet height (UK): 34.8 cm
Technical details
Font styles: ANK, Traditional Chinese, Simplified Chinese
Box contents: AC adapter, C, Main unit, Ribbon, Roll paper, User manual
Paper size roll paper: 76.00 ± 0.50 (W) mm x dia 83.00 mm,
69.50 ± 0.50 (W) mm x dia 83.00 mm,
57.50 ± 0.50 (W) mm x dia 83.00 mm
Technology: Serial Impact Dot Matrix
Voltage: 24 V
Power consumption: Printing: Appx.31 W, Standby: Appx.2 W
Other features
Buffer size: 20 KB
