Epson EB-L690SE. Projector brightness: 6000 ANSI lumens, Projection technology: 3LCD, Projector native resolution: WUXGA (1920×1200). Light source type: Laser, Service life of light source: 20000 h, Service life of light source (economic mode): 30000 h. Focus: Manual, Focal length range: 7.54 – 10.55 mm, Aperture range (F-F): 1.8 – 2. Video processing: 10 bit, Colour modes (2D): Cinema, Dynamic, Natural, DICOM SIM, Presentation, Video colour modes: BT.709, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation. Serial interface type: RS-232C
Designed for compact spaces, the EB-L690SE short-throw offers 6,000 lumens of bright WUXGA resolution with 4K Enhancement, HDR and advanced installation features. With up to 30,000 hours of maintenance-free projection in Eco mode, lens shift, 1.4x zoom and corner focus, it’s ideal for professional applications. Flexible control options are available via HDBaseT, LAN and more.
Awe-inspiring immersive short throw projector
Create stunning, shadow-free presentations in compact spaces with a short throw ratio of 0.5–0.7:1, built-in lens shift, and WUXGA resolution with 4K Enhancement. With 1.4x optical zoom, corner focus, and display sizes up to 500″, this high-performance display is perfect for immersive applications. Its compact design, low noise, and sleek white chassis ensure crystal-clear images in any setting, all at an affordable price.
Flexible installation for professional setups
Designed for easy installation, the EB-L690SE can be quickly configured for optimal performance in any room layout. Features like lens shift, horizontal and vertical keystone correction, and 360° projection ensure precise image positioning. Options such as split-screen capabilities, edge blending, and geometry correction, along with the optional ELPEC01 camera and Epson Projector Professional Tool, enable fast setup and calibration, enhancing flexibility for complex setups.
Stream, share, and connect with ease
With optional wireless connectivity, a USB-A port for PC-free operation, and HDBaseT/HDMI daisy chaining, the EB-L690SE enhances installation flexibility and convenience.
Smart control for seamless experience
The EB-L690SE streamlines large-scale deployments with NFC functionality and the Epson Projector Config Tool. The intuitive OSD menu, coupled with Epson’s EPMC solution, enables effortless cloud monitoring and management. Compatible with Crestron XiO Cloud, it offers centralised control for seamless operation.
Peace of mind with high durability and support
Engineered for long-lasting performance, the EB-L690SE features fit-and-forget laser technology, backed by a 3-year warranty. It minimises maintenance needs, reduces downtime, and offers peace of mind with Epson’s renowned after-sales support.
Environmentally friendly design
Built with sustainability in mind, our projectors are manufactured using 100% renewable electricity* and packaged in 100% recyclable cardboard. With low maintenance and energy consumption and benefits from end-of-life recycling and energy recovery services across Europe.
Screen size compatibility: 2540 – 12700 mm (100 – 500″)
Projection distance: 1.09 – 7.84 m
Projection distance (wide): 1.1 – 5.6 m
Projection distance (tele): 1.5 – 7.8 m
Contrast ratio (dynamic): 5000000:1
Projector brightness: 6000 ANSI lumens
Projection technology: 3LCD
Projector native resolution: WUXGA (1920×1200)
Contrast ratio (typical): 5000000:1
Native aspect ratio: 16:10
Number of colours: 1.07 billion colours
Projector brightness (economic mode): 4200 ANSI lumens
Keystone correction, horizontal: ±30°
Keystone correction, vertical: ±30°
Light source
Light source type: Laser
Service life of light source: 20000 h
Service life of light source (economic mode): 30000 h
Lens system
Focus: Manual
Focal length range: 7.54 – 10.55 mm
Aperture range (F-F): 1.8 – 2
Feature: Zoom capability
Zoom type: Manual
Zoom ratio: 1.4:1
Throw ratio: 0.50 – 0.70:1
Horizontal lens shift range: -20 – -20%
Vertical lens shift range: -50 – -50%
Video
Analog signal format system: Not supported
Feature: Full HD
Video processing: 10 bit
Colour modes (2D): Cinema, Dynamic, Natural, DICOM SIM, Presentation
Video colour modes: BT.709, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation
Ports & interfaces
HDMI version: 2.3
Feature: HDBaseT port
USB 2.0 ports quantity: 3
USB 2.0 Type-A ports quantity: 2
USB 2.0 Type-B ports quantity: 1
Serial interface type: RS-232C
HDMI ports quantity: 2
Network
Feature: Ethernet LAN
Feature: Wi-Fi
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Feature: Miracast
Feature: Apple AirPlay 2 support
Features
Noise level (economic mode): 26 dB
Feature: HDCP
Preset modes: Cinema, Dynamic, Presentation
Noise level: 36 dB
Country of origin: Philippines
Feature: Password protection
Multimedia
Feature: Built-in speaker(s)
RMS rated power: 10 W
Design
Market positioning: Education
Product type: Short throw projector
Product colour: White
Placement: Ceiling, Desktop
Feature: Cable lock slot
Cable lock slot type: Kensington
Power
Power source: AC
Power consumption (typical): 362 W
Power consumption (standby): 0.4 W
Power consumption (max): 415 W
Power consumption (economy mode): 250 W
AC input voltage: 100 – 240 V
AC input frequency: 50 – 60 Hz
AC adapter output voltage: 100 – 240 V
Operational conditions
Storage temperature (T-T): -10 – 60 °C
Operating relative humidity (H-H): 20 – 80%
Storage relative humidity (H-H): 10 – 90%
Weight & dimensions
Width: 440 mm
Depth: 368 mm
Height: 151 mm
Weight: 9.3 kg
Package width: 510 mm
Package depth: 545 mm
Package height: 230 mm
Package weight: 13.3 kg
Packaging content
Feature: Remote control included
Feature: Batteries included
Technical details
Warranty period: 3 year(s)
Power consumption: 362 Watt (Normal On-Mode), 250 Watt (Eco On-Mode), 415 Watt (Normal Peak-mode), 303 Watt (Eco Peak-Mode), 0.4 Watt (Energy saving standby)
Logistics data
Quantity per pack: 1 pc(s)
Other features
Control panel: 0.67 inch with C2 Fine
Supported network protocols: HTTPS, SNMP, ESC/VP.net, PJLink
Box contents: Main unit, Power cable, Quick Start Guide, Remote control incl. batteries, User guide, Warranty document
Security features: Kensington lock, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Password protection
