Elo Touch Solutions 0702L. Display diagonal: 17.8 cm (7"), Display technology: LCD/TFT, Display resolution: 800 x 480 pixels, Display brightness: 500 cd/m², Touchscreen. Product colour: Black
Single-Cable Connection
Using DisplayLink technology, the 0702L provides a single-cable solution that combines power, video and touch signals into one USB connection. By reducing the number of cables from 3 to 1, installation is a breeze, and you never have to worry about a power adapter again. DisplayLink technology supports Windows, Android and Linux operating systems.
Well-Suited for…
Every business is different. Whether you need a customer-facing, point-of-sale touchscreen to display a transaction or an interactive display in a restaurant to enable guests to view the menu and make their orders, the 0702L provides the features to meet your installation needs with a modern, sleek aesthetic.
Mount With Flexibility
Customers demand a seamless shopping experience from the moment they enter the store through check-out. From stands and pole mounts to shelf mounts, wall mounts and 3rd-party VESA mounts, the touchscreens can be integrated with ease.
Brilliant Displays from 7 to 27-inches
The clear glass touchscreens with Elo’s industry-leading TouchPro® PCAP technology offer wide viewing angles with impeccable image clarity, resolution and light transmission for accurate touch response and vivid images. Capable of handling up to 10 simultaneous touches, the 02-Series touchscreen monitors provide an enhanced tablet-like experience.
EloCareSM – We Have Your Back
When a technology outage happens, retailers, restaurants and business operators want to know the right person to call, right away. EloCare offers services you can count on in case the unexpected happens.
Built-to-Last
The 02-Series Touchscreen Monitors deliver the quality and reliability Elo is known for and are backed by our 3-year standard warranty with an optional extension to 5 years. We pride ourselves on being one of the best manufacturers in the market—we design and build the complete solution, with touch integrated from the start. Our robust touchscreen solutions offer flexibility for diverse environments and have undergone rigorous testing to ensure the longest life possible for our products, and your maximum ROI.
Display diagonal: 17.8 cm (7″)
Display technology: LCD/TFT
Display resolution: 800 x 480 pixels
Display brightness: 500 cd/m²
Feature: Touchscreen
Touchscreen technology: Projected capacitive system
Number of simultaneous touchpoints: 10
Response time: 25 ms
Contrast ratio (typical): 500:1
Viewing angle, horizontal: 150°
Viewing angle, vertical: 120°
Display number of colours: 16.2 million colours
Design
Product colour: Black
Screen shape: Flat
Feature: VESA mounting
Panel mounting interface: 75 x 75 mm
Performance
International Protection (IP) code: IP54, IP65
Power
Power consumption (typical): 3.7 W
Power consumption (off): 1.9 W
Packaging data
Package width: 232 mm
Package depth: 95 mm
Package height: 170 mm
Package weight: 650 g
Packaging content
Cables included: Micro-USB
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Operating relative humidity (H-H): 20 – 80%
Storage temperature (T-T): -20 – 60 °C
Storage relative humidity (H-H): 10 – 95%
Certificates
Certification: cUL, IC, CCC, CE, FCC, UL, VCCI, CB, RCM, NOM
Logistics data
Harmonized System (HS) code: 85285210
Features
Feature: Wall mountable
Other features
Micro-USB ports quantity: 1
Maximum refresh rate: 60 Hz
Feature: Quick start guide
Aspect ratio: 5:3
Display viewable area (HxV): 154.08 x 85.92 mm
Height (without stand): 17.7 mm
Weight (without stand): 350 g
Depth (without stand): 117.2 mm
