Digitus 5 Port Gigabit Switch, Unmanaged. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. Full duplex. MAC address table: 2000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x. DC input voltage: 5 V
– Expands your network by 4 additional ports
– Auto-MDI/MDIX & Auto-negotiation
– Energy-Efficient Ethernet (EEE) IEEE802.3az
– Full-duplex flow control IEEE802.3x
– Fanless design without noise
– Sturdy metal housing
– Plug and Play – no configuration or software required
– Suitable for use on the desktop
– Ideal for home and small offices
The 5-Port Gigabit Switch from DIGITUS® is perfectly suited for the easy expansion of your network. Thanks to its fanless design, the switch operates completely noise-free and does not require configuration. Each port can be used as a LAN or uplink port, the cable and network speed are detected automatically. The switch also supports the energy saving features IEEE802.3az & Full-Duplex Flow Control IEE802.3x. Real Plug and Play – Just plug in the network cable and get started.
Switch type: Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 5
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Feature: Full duplex
Feature: Flow control support
Feature: Auto MDI/MDI-X
Ethernet LAN data rates: 10,100,1000 Mbit/s
Data transmission
Switching capacity: 10 Gbit/s
Throughput: 7.44 Mpps
MAC address table: 2000 entries
Feature: Store-and-forward
Design
Product colour: Black
LED indicators: Activity, Link, Power
Performance
Feature: Plug and Play
Feature: Fanless
Power
Power source: DC
AC input voltage: 100 – 240 V
AC input frequency: 50/60 Hz
DC input voltage: 5 V
Input current: 1 A
Power consumption (max): 3 W
Power plug type: Type C
Other features
Ethernet interface type: Gigabit Ethernet
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Storage temperature (T-T): -10 – 70 °C
Operating relative humidity (H-H): 10 – 90%
Weight & dimensions
Width: 69 mm
Depth: 92 mm
Height: 25 mm
Weight: 180 g
Packaging content
Feature: Quick start guide
Packaging data
Feature: AC adapter included
Package width: 140 mm
Package depth: 70 mm
Package height: 189 mm
Package weight: 425 g
Logistics data
UK Trade Tariff code: 85176200
Country of origin: China
