Digitus Industrial Gigabit Ethernet PoE+ Injector, 802.3 af/at, 60 W. Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3at. Product colour: Black, LED indicators: PoE, Power, Power protection features: Over voltage, Short circuit. Power over Ethernet (PoE) voltage: 55 V, Output power: 60 W, Power consumption (max): 3 W. Weight: 300 g, Dimensions (WxDxH): 77 x 103 x 32 mm. Number of products included: 1 pc(s)
– Industrial Gigabit PoE+ Injector 802.3 af/at
– Meets the 802.3af/at PoE standard
– 48~55V output voltage, 60W
The Digitus PoE Injector allows you to minimize cabling during installation of PoE-ready devices such as IP network cameras. Data supply and power supply to the devices is accomplished using a single Ethernet cable. This makes laying a separate power cable unnecessary and allows you to extend your network to places where there are no outlets or power cables. The Injector is fully compliant with the IEEE802.3at Ultra PoE standard and delivers an output power of 60 W.
Ethernet interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Feature: Power over Ethernet (PoE)
Networking standards: IEEE 802.3at
Features
Product colour: Black
Feature: Wall mountable
LED indicators: PoE, Power
Power protection features: Over voltage, Short circuit
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
Feature: DC-in jack
Power
Power over Ethernet (PoE) voltage: 55 V
Output power: 60 W
Power consumption (max): 3 W
Total Power over Ethernet (PoE) budget: 60 W
Operational conditions
Operating temperature (T-T): -40 – 75 °C
Weight & dimensions
Weight: 300 g
Dimensions (WxDxH): 77 x 103 x 32 mm
Packaging content
Number of products included: 1 pc(s)
Feature: Quick installation guide
Packaging data
Package width: 125 mm
Package depth: 165 mm
Package height: 50 mm
Package weight: 410 g
Package volume: 1031.25 cm³
Logistics data
UK Trade Tariff code: 85044095
Harmonized System (HS) code: 85044095
Master (outer) case width: 350 mm
Master (outer) case height: 330 mm
Master (outer) case gross weight: 390 g
Master (outer) case volume: 45045 cm³
Products per master (outer) case: 36 pc(s)
Country of origin: China
