DELL R570. Processor family: Intel Xeon 6, Processor frequency: 3.2 GHz, Processor model: 6517P. Internal memory: 32 GB, Internal memory type: DDR5-SDRAM, Memory layout (slots x size): 1 x 32 GB. Total storage capacity: 1.92 TB. Power supply: 1100 W, Redundant power supply (RPS) support. Chassis type: Rack (2U)
Simple, Scalable and Efficient Solutions
The Dell PowerEdge R570 is a 2U, one-socket rack server engineered for high-performance computing with exceptional power efficiency and balanced performance, driving cost savings and boosting data center productivity.
The Dell PowerEdge R570 is a 2U, one-socket rack server engineered for high-performance computing with exceptional power efficiency and balanced performance, driving cost savings and boosting data center productivity.
Processor
Processor manufacturer: Intel
Processor family: Intel Xeon 6
Processor model: 6517P
Processor frequency: 3.2 GHz
Processor boost frequency: 4.2 GHz
Processor cores: 16
Processor cache: 72 MB
Number of processors installed: 1
Thermal Design Power (TDP): 190 W
System bus rate: 24 GT/s
Processor threads: 32
Memory types supported by processor: DDR5-SDRAM
Memory clock speeds supported by processor: 6400 MHz
Memory
Internal memory: 32 GB
Internal memory type: DDR5-SDRAM
Buffered memory type: Registered (buffered)
Memory ranking: 2
Memory slots: 16x DIMM
Memory layout (slots x size): 1 x 32 GB
Memory data transfer rate: 6400 MT/s
Maximum internal memory: 1 TB
Storage
Total storage capacity: 1.92 TB
Number of SSDs installed: 2
SSD capacity: 960 GB
SSD interface: SATA III
SSD size: 2.5″
Supported SSD sizes: 2.5″
Number of SSDs supported: 16
Feature: RAID support
Supported RAID controllers: PERC H965i Controller, Front, DC-MHS
Feature: Hot-Plug support
Optical drive type: No
Drive writes per day (DWPD): 1
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
USB 2.0 ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
VGA (D-Sub) ports quantity: 1
Expansion slots
PCI Express x16 (Gen 5.x) slots: 2
Design
Chassis type: Rack (2U)
Product colour: Black
Feature: Bezel
Performance
Remote administration: iDRAC10, Enterprise 17G
Software
Operating system installed: No
Compatible operating systems: Canonical Ubuntu Server LTS RedHat Enterprise LinuxSUSE Linux Enterprise ServerVMware ESXiWindows ServerWindows Server Datacenter
Power
Feature: Redundant power supply (RPS) support
Power supply: 1100 W
Number of redundant power supplies installed: 2
Power supply input voltage: 100 – 240 V
Certificates
80 PLUS certification: 80 PLUS Titanium
Carbon footprint
Total carbon footprint (kg of CO2e): 1247
Total carbon emissions, standard deviation (kg of CO2e): 101
Carbon emissions, manufacturing (kg of CO2e): 463.88
Carbon emissions, logistics (kg of CO2e): 209.5
Carbon emissions, energy usage (kg of CO2e): 537.46
Carbon emissions, end-of-life (kg of CO2e): 37.41
PAIA version: PAIA 1.4.7, 2025
Weight & dimensions
Width: 482 mm
Height: 86.8 mm
Packaging content
Packaging content: 2x Rack Power Cord 2M (C13/C14 12A) – FGA Only2U Combo Drop-In/Stab-In Rails,Riser Config 5
Other features
Data transfer rate: 6 Gbit/s
Bytes per sector: 512e
Target workload: Read Intensive (RI)
Open Compute Project (OCP): 1×16 FLOP, 1×16 Onboard, 1 Rear Blank
Processor manufacturer: Intel
Processor family: Intel Xeon 6
Processor model: 6517P
Processor frequency: 3.2 GHz
Processor boost frequency: 4.2 GHz
Processor cores: 16
Processor cache: 72 MB
Number of processors installed: 1
Thermal Design Power (TDP): 190 W
System bus rate: 24 GT/s
Processor threads: 32
Memory types supported by processor: DDR5-SDRAM
Memory clock speeds supported by processor: 6400 MHz
Memory
Internal memory: 32 GB
Internal memory type: DDR5-SDRAM
Buffered memory type: Registered (buffered)
Memory ranking: 2
Memory slots: 16x DIMM
Memory layout (slots x size): 1 x 32 GB
Memory data transfer rate: 6400 MT/s
Maximum internal memory: 1 TB
Storage
Total storage capacity: 1.92 TB
Number of SSDs installed: 2
SSD capacity: 960 GB
SSD interface: SATA III
SSD size: 2.5″
Supported SSD sizes: 2.5″
Number of SSDs supported: 16
Feature: RAID support
Supported RAID controllers: PERC H965i Controller, Front, DC-MHS
Feature: Hot-Plug support
Optical drive type: No
Drive writes per day (DWPD): 1
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
USB 2.0 ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
VGA (D-Sub) ports quantity: 1
Expansion slots
PCI Express x16 (Gen 5.x) slots: 2
Design
Chassis type: Rack (2U)
Product colour: Black
Feature: Bezel
Performance
Remote administration: iDRAC10, Enterprise 17G
Software
Operating system installed: No
Compatible operating systems: Canonical Ubuntu Server LTS RedHat Enterprise LinuxSUSE Linux Enterprise ServerVMware ESXiWindows ServerWindows Server Datacenter
Power
Feature: Redundant power supply (RPS) support
Power supply: 1100 W
Number of redundant power supplies installed: 2
Power supply input voltage: 100 – 240 V
Certificates
80 PLUS certification: 80 PLUS Titanium
Carbon footprint
Total carbon footprint (kg of CO2e): 1247
Total carbon emissions, standard deviation (kg of CO2e): 101
Carbon emissions, manufacturing (kg of CO2e): 463.88
Carbon emissions, logistics (kg of CO2e): 209.5
Carbon emissions, energy usage (kg of CO2e): 537.46
Carbon emissions, end-of-life (kg of CO2e): 37.41
PAIA version: PAIA 1.4.7, 2025
Weight & dimensions
Width: 482 mm
Height: 86.8 mm
Packaging content
Packaging content: 2x Rack Power Cord 2M (C13/C14 12A) – FGA Only2U Combo Drop-In/Stab-In Rails,Riser Config 5
Other features
Data transfer rate: 6 Gbit/s
Bytes per sector: 512e
Target workload: Read Intensive (RI)
Open Compute Project (OCP): 1×16 FLOP, 1×16 Onboard, 1 Rear Blank
