DELL Pro QVS1260

Processor
Processor manufacturer: Intel
Processor family: Intel Core Ultra 5
Processor generation: Intel Core Ultra (Series 2)
Processor model: 225
Processor cores: 10
Processor threads: 10
Processor boost frequency: 4.9 GHz
Performance cores: 6
Efficient cores: 4
Performance-core Max Turbo Frequency: 4.9 GHz
Efficient-core Max Turbo Frequency: 4.4 GHz
Performance-core base frequency: 3.3 GHz
Efficient-core base frequency: 2.7 GHz
Processor cache: 20 MB
Processor cache type: Smart Cache
Number of processors installed: 1
Processor base power: 65 W
Maximum turbo power: 121 W
Neural processor unit (NPU)
Neural processor unit (NPU): Intel AI Boost
Feature: Sparsity support
Feature: Windows Studio effects support
AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to: 23 TOPs
NPU performance up to: 13 TOPs
GPU performance up to: 4 TOPs
Memory
Internal memory: 16 GB
Maximum internal memory: 32 GB
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 1 x 16 GB
Memory slots: 2x DIMM
Buffered memory type: Unregistered (unbuffered)
Memory data transfer rate: 4800 MT/s
Storage
Total storage capacity: 512 GB
Storage media: SSD
Optical drive type: No
Total SSDs capacity: 512 GB
Number of SSDs installed: 1
SSD capacity: 512 GB
SSD interface: PCI Express 3.0
Feature: NVMe
SSD form factor: M.2
Graphics
Feature: On-board graphics card
Discrete graphics card model: Not available
On-board GPU manufacturer: Intel
On-board graphics card family: Intel® Graphics
On-board graphics card model: Intel® Graphics
Performance
Motherboard chipset: Intel Q670
Feature: Trusted Platform Module (TPM)
Product type: PC
Trusted Platform Module (TPM) version: 2.0
Network
Feature: Ethernet LAN
Ethernet LAN data rates: 10,100,1000 Mbit/s
Cabling technology: 10/100/1000Base-T(X)
LAN controller: Realtek RTL8111KD
Feature: Wi-Fi
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi standards: Wi-Fi 6 (802.11ax)
WLAN controller manufacturer: MediaTek
WLAN controller model: MediaTek MT7920
Antenna type: 2×2
Feature: Bluetooth
Feature: MU-MIMO
Ports & interfaces
USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
DisplayPorts quantity: 1
DisplayPort version: 1.4
HDMI ports quantity: 1
HDMI version: 2.1
Ethernet LAN (RJ-45) ports: 1
Feature: Combo headphone/mic port
Number of rear USB ports: 4
Number of front USB ports: 4
Number of SATA III connectors: 1
Expansion slots
PCI Express x1 slots: 3
PCI Express x16 slots: 1
Power
Power supply: 180 W
Power supply input voltage: 90 – 264 V
Power supply input frequency: 47 – 63 Hz
80 PLUS certification: 80 PLUS Bronze
Design
Chassis type: Slim PC
Feature: Cable lock slot
Cable lock slot type: Kensington
Product colour: Black
Software
Operating system architecture: 64-bit
Operating system installed: Windows 11 Pro
Trial software: McAfee® Business Protection 1-year,Activate Your Microsoft 365 For A 30 Day Trial
Audio
Audio chip: Realtek ALC3204
Audio system: High Definition Audio
Operational conditions
Operating temperature (T-T): 10 – 35 °C
Storage temperature (T-T): -40 – 65 °C
Operating relative humidity (H-H): 20 – 80%
Storage relative humidity (H-H): 5 – 95%
Operating altitude: -15.2 – 3048 m
Non-operating altitude: -15.2 – 10668 m
Operating vibration: 0.26 G
Non-operating vibration: 1.37 G
Operating shock: 40 G
Non-operating shock: 105 G
Weight & dimensions
Width: 95 mm
Depth: 293 mm
Height: 303.5 mm
Packaging content
Cables included: AC
Carbon footprint
Total carbon footprint (kg of CO2e): 143
Carbon emissions, manufacturing (kg of CO2e): 68.07
Carbon emissions, logistics (kg of CO2e): 9.15
Carbon emissions, energy usage (kg of CO2e): 62.78
Carbon emissions, end-of-life (kg of CO2e): 3
PAIA version: GaBi version 1, 2025
