D-Link DGS-1100-24PV2. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 8000 entries, Switching capacity: 48 Gbit/s. Networking standards: IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE…. Power over Ethernet (PoE). Rack mounting
The DGS-1100 Series is a range of powerful switches that offer a lot of bang for your buck. They are great for busy SMBs who expect a lot of their network, including support for surveillance and VoIP. They are packed with traffic management & optimization features that keep your network congestion free. Meanwhile, management tools are flexible and intuitive, making your life easier.
Gigabit Ethernet Speeds
Take your Ethernet speeds to the next level with Gigabit Connectivity
Cutting Edge Green Technology
Innovative D-Link Green power saving features keep your budget in check
Manage Anywhere, Anytime
Remote setup & management is easy, and can be done from anywhere.
Easy to Use & Easy to Install
D-Link Network Assistant Utility (DNA) can quickly discover and do initial setup for D-Link Networking devices such as the DGS-1100 Series, which greatly improves efficiency for solution deployment.
VLANs: Stronger Security & Better Traffic Management
Relatively easy to set up, VLANs can be a big boon for your network. They can isolate sensitive areas of your network, keeping them safe from those with malicious intent, or keeping bandwidth open for latency-sensitive traffic such as VoIP.
For Voice
If VoIP calls make up a large slice of your network usage, separating them onto their own VLAN can ensure they get the bandwidth they need for smooth conversations without lag or jitters.
For Surveillance
If you have surveillance cameras and devices attached to your network, putting them onto their own VLAN keeps surveillance footage running seamlessly. At the same time, it can help prevent a variety of malicious attacks by restricting access to different network areas.
Green Technology
D-Link Green technology enables the DGS-1100 Smart Managed Switches to save power without sacrificing performance. Most of the models in the series utilize a fanless design, for silent and energy-efficient operation. All are IEEE 802.3az-compliant and feature Link Status detection and Time-Based PoE.
Switch type: Managed
Switch layer: L2
Feature: Quality of Service (QoS) support
Feature: Web-based management
Feature: System event log
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
Copper ethernet cabling technology: 10BASE-T, 10BASE-TX, 1000BASE-T
Feature: Port mirroring
Feature: Full duplex
Feature: Flow control support
Feature: Link aggregation
Feature: Broadcast storm control
Feature: Rate limiting
Feature: Auto MDI/MDI-X
Feature: Spanning tree protocol
Feature: Head-of-line (HOL) blocking
Feature: Auto-negotiation
Feature: VLAN support
Virtual LAN features: Port-based VLAN, Voice VLAN
Number of VLANs: 128
Data transmission
Switching capacity: 48 Gbit/s
Forwarding rate: 35.71 Mpps
MAC address table: 8000 entries
Feature: Store-and-forward
Number of queues: 4
Feature: Jumbo frames support
Jumbo frames: 9216
Packet buffer memory: 4.1 MB
Security
DHCP features: DHCP client
Feature: IGMP snooping
Security algorithms: SNMP, SSL/TLS
Queue scheduling algorithms: SPQ, Weighted Round Robin (WRR)
Multicast features
Feature: Multicast support
Design
Feature: Rack mounting
Product colour: Black
LED indicators: Yes
Performance
Feature: Built-in processor
Processor frequency: 125 MHz
Memory type: DRAM
Flash memory: 16 MB
Noise level: 0 dB
Feature: Fanless
Mean time between failures (MTBF): 255003 h
Power
AC input voltage: 100 – 240 V
Power consumption (max): 19.5 W
Power over Ethernet (PoE)
Feature: Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 12
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 100 W
Operational conditions
Operating temperature (T-T): -5 – 50 °C
Storage temperature (T-T): -40 – 70 °C
Operating relative humidity (H-H): 0 – 95%
Storage relative humidity (H-H): 0 – 95%
Operating altitude: 0 – 2000 m
Heat dissipation: 107.5 BTU/h
Weight & dimensions
Width: 280 mm
Depth: 230 mm
Height: 44 mm
Weight: 2.2 kg
Certificates
Certification: EMI FCC A, CE A, VCCI A, C-Tick, BSMI, CCCcUL, CE LVD, CB, BSMI, CCC
