CyberPower PR2000ERT2UC. UPS topology: Line-Interactive, Output power capacity: 2 kVA, Output power: 2000 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 10 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 4 min, Typical backup time at half load: 13 min. Form factor: Rackmount/Tower, Product colour: Black, Housing material: Metal. Compliance certificates: CE, Federal Communications Commission (FCC), RCM, RoHS, UL, VCCI
The UPS’s output power factor is 1, which means it is capable of connecting to more critical loads than conventional UPS. It also features Battery Management Technology to help batteries obtain optimal life span by balancing battery string voltage. Two-phase battery charging can charge the battery quickly and safely. The hot-swappable battery packs allow for easy maintenance without power interruption. Its multi-functional matrix LCD supports intuitive operation and quick configuration. The LCD panel is also rotatable to meet installation requirements.
UPS topology: Line-Interactive
Output power capacity: 2 kVA
Output power: 2000 W
Waveform: Pure sine
Input operation voltage (min): 200 V
Input operation voltage (max): 240 V
Input frequency: 50/60 Hz
Output operation voltage (min): 220 V
Output operation voltage (max): 240 V
Output frequency: 50/60 Hz
Feature: Automatic Voltage Regulation (AVR)
Maximum current: 16 A
Surge energy rating: 2430 J
Response time: 6 ms
Heat dissipation: 96.7 BTU/h
Number of input phases: 1
Number of output phases: 1
Output power factor: 1
Power Factor Correction (PFC) type: Active
Feature: Emergency Power Off (EPO)
Feature: EMI/RFI noise filtering
Feature: Surge protection
Power protection features: Overload
Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm
Power source type: AC
Feature: Detachable power cord
Ports & interfaces
AC outlet types: C13 coupler
Power plug: C14 coupler
AC outlets quantity: 10 AC outlet(s)
Feature: USB port
USB 2.0 ports quantity: 1
USB port type: USB Type-B
Feature: Serial interface
Serial interface type: RS-232
Serial ports quantity: 2
RS-232 ports: 2
Ethernet LAN (RJ-45) ports: 2
Feature: Emergency Power Off (EPO) connector
Battery
Battery technology: Sealed Lead Acid (VRLA)
Number of batteries supported: 1
Typical backup time at full load: 4 min
Typical backup time at half load: 13 min
Battery recharge time: 3 h
Feature: Hot-swap battery
Design
Form factor: Rackmount/Tower
Housing material: Metal
Rack capacity: 2U
Extended battery module rack capacity: 2U
Cable length: 3.05 m
Cooling type: Active
Feature: Built-in fan
Product colour: Black
Control type: Buttons
Display type: LCD
LED indicators: Yes
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Storage temperature (T-T): -15 – 45 °C
Operating relative humidity (H-H): 0 – 95%
Storage relative humidity (H-H): 0 – 95%
Operating altitude: 0 – 3000 m
Non-operating altitude: 0 – 15000 m
Certificates
Compliance certificates: CE, Federal Communications Commission (FCC), RCM, RoHS, UL, VCCI
Packaging content
Feature: Batteries included
Feature: Rack mount kit
Cables included: Serial
Feature: Manual
Sustainability
Feature: Sustainability compliance
Weight & dimensions
Width: 433 mm
Depth: 500 mm
Height: 86.5 mm
Weight: 32 kg
Packaging data
Package width: 560 mm
Package depth: 620 mm
Package height: 275 mm
Package weight: 38.8 kg
Package type: Box
Logistics data
Country of origin: China
Other features
Battery type: RBP0128
