CyberPower OLS1500ERT2UA. UPS topology: Double-conversion (Online), Output power capacity: 1.5 kVA, Output power: 1350 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 8 AC outlet(s). Battery voltage: 48 V, Typical backup time at full load: 5.3 min, Typical backup time at half load: 15.3 min. Form factor: Rackmount/Tower, Product colour: Black, Housing material: Metal. Compliance certificates: CE, RoHS
The UPS features color LCD panel for users to monitor power system and configure settings easily, and relay-type dry contact to perform local management. This model is designed with extended battery module auto-detection, which can automatically detect the quantity of connected Extended Battery Modules (EBM) to estimate UPS’s runtime. The variable speed fans provide automatic thermal management based on power load to reduce noise and provide greater comfort for users.
UPS topology: Double-conversion (Online)
Output power capacity: 1.5 kVA
Output power: 1350 W
Waveform: Pure sine
Input operation voltage (min): 190 V
Input operation voltage (max): 300 V
Input frequency: 50/60 Hz
Output operation voltage (min): 208 V
Output operation voltage (max): 240 V
Output frequency: 50/60 Hz
Maximum current: 9 A
Surge energy rating: 363 J
Response time: 0 ms
Efficiency (ECO mode): 95%
Input power factor: 0.99
Output power factor: 0.9
Crest factor: 3:1
Feature: Emergency Power Off (EPO)
Output voltage Total Harmonic Distortion (THD): 5%
Feature: EMI/RFI noise filtering
Noise level: 45 dB
Feature: Surge protection
Power protection features: Input fuse, Overload, Short circuit
Feature: Audible alarm(s)
Audible alarm modes: Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
Ports & interfaces
AC outlet types: C13 coupler
Power plug: C14 coupler
AC outlets quantity: 8 AC outlet(s)
Feature: USB port
Ethernet LAN (RJ-45) ports: 2
Feature: Emergency Power Off (EPO) connector
Battery
Battery voltage: 48 V
Number of batteries supported: 4
Typical backup time at full load: 5.3 min
Typical backup time at half load: 15.3 min
Battery recharge time: 4 h
Charging current: 1.5 A
Replacement battery cartridge: BPSE48V40ART2U
Design
Form factor: Rackmount/Tower
Housing material: Metal
Rack capacity: 2U
Cable length: 1.5 m
Feature: Built-in fan
Product colour: Black
Display type: LCD
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Storage temperature (T-T): -20 – 50 °C
Operating relative humidity (H-H): 20 – 90%
Storage relative humidity (H-H): 10 – 90%
Operating altitude: 0 – 1500 m
Non-operating altitude: 0 – 1500 m
Certificates
Compliance certificates: CE, RoHS
Packaging content
Cables included: USB cable
Weight & dimensions
Width: 438 mm
Depth: 430 mm
Height: 88 mm
Weight: 13.8 kg
Packaging data
Package width: 540 mm
Package depth: 550 mm
Package height: 230 mm
Package weight: 20.5 kg
Logistics data
Harmonized System (HS) code: 8504408590
Country of origin: China
