CyberPower OLS1500EA. UPS topology: Double-conversion (Online), Output power capacity: 1.5 kVA, Output power: 1350 W. AC outlet types: IEC 320, Power plug: C13 coupler, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 5.3 min, Typical backup time at half load: 15.3 min. Form factor: Tower, Product colour: Black, Housing material: Metal. Compliance certificates: CE, Certification: RoHS
The UPS is designed with color LCD panel for users to monitor power system and configure settings easily. This model is generator compatible and also adopts ECO mode to conserve power. The product can be connected to Emergency Power Off (EPO) switch, which allows users to shut off UPS immediately during emergency. The variable speed fans provide automatic thermal management based on power load to reduce noise and provide greater comfort for users.
UPS topology: Double-conversion (Online)
Output power capacity: 1.5 kVA
Output power: 1350 W
Waveform: Pure sine
Input operation voltage (min): 190 V
Input operation voltage (max): 300 V
Input frequency: 50/60 Hz
Output operation voltage (min): 208 V
Output operation voltage (max): 240 V
Output frequency: 50/60 Hz
Maximum current: 9 A
Surge energy rating: 345 J
Response time: 0 ms
Efficiency (ECO mode): 95%
Power factor: 0.9
Input power factor: 0.98
Output voltage Total Harmonic Distortion (THD): 5%
Feature: EMI/RFI noise filtering
Feature: Surge protection
Power protection features: Overload
Feature: Audible alarm(s)
Audible alarm modes: Battery replacement, Fault, Low battery alarm, Overload alarm
Ports & interfaces
AC outlet types: IEC 320
Power plug: C13 coupler
AC outlets quantity: 4 AC outlet(s)
Number of output IEC jumpers: 2
Feature: USB port
USB 2.0 ports quantity: 1
Feature: Emergency Power Off (EPO) connector
Battery
Battery technology: Sealed Lead Acid (VRLA)
Typical backup time at full load: 5.3 min
Typical backup time at half load: 15.3 min
Battery recharge time: 4 h
Charging current: 1.5 A
Design
Form factor: Tower
Housing material: Metal
Cable length: 1.5 m
Product colour: Black
Display type: LCD
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Storage temperature (T-T): -20 – 50 °C
Operating relative humidity (H-H): 20 – 90%
Storage relative humidity (H-H): 10 – 90%
Operating altitude: 0 – 1500 m
Non-operating altitude: 0 – 1500 m
Certificates
Compliance certificates: CE
Certification: RoHS
Packaging content
Cables included: USB cable
Feature: Manual
Weight & dimensions
Width: 151 mm
Depth: 394 mm
Height: 225 mm
Weight: 14.4 kg
Packaging data
Package width: 241 mm
Package depth: 510 mm
Package height: 313 mm
Package weight: 16.2 kg
Logistics data
Harmonized System (HS) code: 8504408590
Country of origin: China
