CyberPower OL3KERTHDL. UPS topology: Double-conversion (Online), Output power capacity: 3 kVA, Output power: 3000 W. AC outlet types: C13 coupler, C19 coupler, Power plug: C19 coupler, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery voltage: 144 V, Typical backup time at full load: 5.7 min. Form factor: Rackmount/Tower, Product colour: Black, Silver, Housing material: Metal. Compliance certificates: CE, EAC, RCM, RoHS
Features
UPS topology: Double-conversion (Online)
Output power capacity: 3 kVA
Output power: 3000 W
Waveform: Pure sine
Input operation voltage (min): 200 V
Input operation voltage (max): 240 V
Input frequency: 50/60 Hz
Output operation voltage (min): 220 V
Output operation voltage (max): 240 V
Output frequency: 50/60 Hz
Output frequency regulation: 10 Hz
Output voltage regulation: 2%
Maximum current: 16 A
Surge energy rating: 2430 J
Response time: 0 ms
Heat dissipation: 709 BTU/h
Number of input phases: 1
Number of output phases: 1
Efficiency (ECO mode): 97%
Input power factor: 0.99
Output power factor: 1
Power Factor Correction (PFC) type: Active
Crest factor: 3:1
Feature: ECO mode
Feature: Emergency Power Off (EPO)
Total Harmonic Distortion (THD) (linear load): 3%
Total Harmonic Distortion (THD) (non-linear load): 5%
Feature: EMI/RFI noise filtering
Noise level: 66 dB
Feature: Surge protection
Power protection features: Overload
Feature: Audible alarm(s)
Audible alarm modes: Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
Power source type: AC
Feature: Socket circuit breaker
Ports & interfaces
AC outlet types: C13 coupler, C19 coupler
Power plug: C19 coupler
AC outlets quantity: 6 AC outlet(s)
Feature: USB port
USB 2.0 ports quantity: 1
Feature: Serial interface
Serial interface type: RS-232
Serial ports quantity: 1
RS-232 ports: 1
Feature: Emergency Power Off (EPO) connector
Battery
Battery technology: Sealed Lead Acid (VRLA)
Battery voltage: 144 V
Number of batteries supported: 1
Typical backup time at full load: 5.7 min
Typical backup time at half load: 12 min
Battery recharge time: 4 h
Feature: Hot-swap battery
Feature: Rechargeable battery
Design
Form factor: Rackmount/Tower
Housing material: Metal
Product colour: Black, Silver
Control type: Buttons
Display type: LCD
LED indicators: Yes
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Storage temperature (T-T): -5 – 45 °C
Operating relative humidity (H-H): 0 – 90%
Storage relative humidity (H-H): 0 – 95%
Operating altitude: 0 – 3000 m
Non-operating altitude: 0 – 4500 m
Certificates
Compliance certificates: CE, EAC, RCM, RoHS
Packaging content
Cables included: Serial, USB cable
Feature: Manual
Feature: Quick installation guide
Sustainability
Feature: Sustainability compliance
Sustainability certificates: ENERGY STAR
Weight & dimensions
Width: 433 mm
Depth: 720 mm
Height: 86.5 mm
Weight: 42 kg
Packaging data
Package width: 600 mm
Package depth: 1100 mm
Package height: 215 mm
Package weight: 52.1 kg
Logistics data
Country of origin: China
Other features
Battery type: RBP0144
Nominal input voltage: 220-240 V
Feature: Overload protection
UPS topology: Double-conversion (Online)
Output power capacity: 3 kVA
Output power: 3000 W
Waveform: Pure sine
Input operation voltage (min): 200 V
Input operation voltage (max): 240 V
Input frequency: 50/60 Hz
Output operation voltage (min): 220 V
Output operation voltage (max): 240 V
Output frequency: 50/60 Hz
Output frequency regulation: 10 Hz
Output voltage regulation: 2%
Maximum current: 16 A
Surge energy rating: 2430 J
Response time: 0 ms
Heat dissipation: 709 BTU/h
Number of input phases: 1
Number of output phases: 1
Efficiency (ECO mode): 97%
Input power factor: 0.99
Output power factor: 1
Power Factor Correction (PFC) type: Active
Crest factor: 3:1
Feature: ECO mode
Feature: Emergency Power Off (EPO)
Total Harmonic Distortion (THD) (linear load): 3%
Total Harmonic Distortion (THD) (non-linear load): 5%
Feature: EMI/RFI noise filtering
Noise level: 66 dB
Feature: Surge protection
Power protection features: Overload
Feature: Audible alarm(s)
Audible alarm modes: Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
Power source type: AC
Feature: Socket circuit breaker
Ports & interfaces
AC outlet types: C13 coupler, C19 coupler
Power plug: C19 coupler
AC outlets quantity: 6 AC outlet(s)
Feature: USB port
USB 2.0 ports quantity: 1
Feature: Serial interface
Serial interface type: RS-232
Serial ports quantity: 1
RS-232 ports: 1
Feature: Emergency Power Off (EPO) connector
Battery
Battery technology: Sealed Lead Acid (VRLA)
Battery voltage: 144 V
Number of batteries supported: 1
Typical backup time at full load: 5.7 min
Typical backup time at half load: 12 min
Battery recharge time: 4 h
Feature: Hot-swap battery
Feature: Rechargeable battery
Design
Form factor: Rackmount/Tower
Housing material: Metal
Product colour: Black, Silver
Control type: Buttons
Display type: LCD
LED indicators: Yes
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Storage temperature (T-T): -5 – 45 °C
Operating relative humidity (H-H): 0 – 90%
Storage relative humidity (H-H): 0 – 95%
Operating altitude: 0 – 3000 m
Non-operating altitude: 0 – 4500 m
Certificates
Compliance certificates: CE, EAC, RCM, RoHS
Packaging content
Cables included: Serial, USB cable
Feature: Manual
Feature: Quick installation guide
Sustainability
Feature: Sustainability compliance
Sustainability certificates: ENERGY STAR
Weight & dimensions
Width: 433 mm
Depth: 720 mm
Height: 86.5 mm
Weight: 42 kg
Packaging data
Package width: 600 mm
Package depth: 1100 mm
Package height: 215 mm
Package weight: 52.1 kg
Logistics data
Country of origin: China
Other features
Battery type: RBP0144
Nominal input voltage: 220-240 V
Feature: Overload protection
