CyberPower OL2200ERTXL2U. UPS topology: Double-conversion (Online), Output power capacity: 2.2 kVA, Output power: 2000 W. AC outlet types: C13 coupler, C19 coupler, Power plug: C20 coupler, AC outlets quantity: 9 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery voltage: 72 V, Typical backup time at full load: 6.5 min. Form factor: Rackmount/Tower, Product colour: Black, Housing material: Metal. Compliance certificates: CE, RoHS
To extend battery lifetime, the UPS adopts Smart Battery Management (SBM) to enhance battery charging process and achieve a lower total cost of ownership. This model also features detachable LCD display panel to relocate the panel for convenient monitoring, and RJ11/RJ45 port to provide data line protection against surges and spikes. The PowerPanel Power Management Software allows user to perform real-time monitoring and remote management of the UPS.
UPS topology: Double-conversion (Online)
Output power capacity: 2.2 kVA
Output power: 2000 W
Waveform: Pure sine
Input operation voltage (min): 190 V
Input operation voltage (max): 300 V
Input frequency: 40/70 Hz
Output operation voltage (min): 200 V
Output operation voltage (max): 240 V
Output frequency: 50/60 Hz
Maximum current: 11 A
Surge energy rating: 1335 J
Response time: 0 ms
Heat dissipation: 1139 BTU/h
Output power factor: 0.9
Feature: Emergency Power Off (EPO)
Total Harmonic Distortion (THD) (linear load): 3%
Total Harmonic Distortion (THD) (non-linear load): 5%
Feature: Surge protection
Surge protection features: Fax, Modem, Network, Telephone
Power protection features: Overload
Ports & interfaces
AC outlet types: C13 coupler, C19 coupler
Power plug: C20 coupler
AC outlets quantity: 9 AC outlet(s)
USB 2.0 ports quantity: 1
Feature: Serial interface
Serial interface type: RS-232
Serial ports quantity: 1
RS-232 ports: 1
Ethernet LAN (RJ-45) ports: 2
Feature: Emergency Power Off (EPO) connector
Battery
Battery technology: Sealed Lead Acid (VRLA)
Battery voltage: 72 V
Typical backup time at full load: 6.5 min
Typical backup time at half load: 20 min
Battery recharge time: 5 h
Charging current: 1 A
Feature: Hot-swap battery
Feature: Cold start
Design
Form factor: Rackmount/Tower
Housing material: Metal
Rack capacity: 2U
Cable length: 3 m
Cooling type: Active
Feature: Built-in fan
Product colour: Black
Control type: Buttons
Display type: LCD
LED indicators: Yes
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Storage temperature (T-T): -20 – 45 °C
Operating relative humidity (H-H): 0 – 90%
Storage relative humidity (H-H): 0 – 95%
Operating altitude: 0 – 3000 m
Non-operating altitude: 0 – 15000 m
Certificates
Compliance certificates: CE, RoHS
Packaging content
Feature: Rack mount kit
Cables included: Serial, USB cable
Feature: Manual
Sustainability
Feature: Sustainability compliance
Weight & dimensions
Width: 433 mm
Depth: 600 mm
Height: 88 mm
Weight: 31 kg
Packaging data
Package width: 565 mm
Package depth: 880 mm
Package height: 240 mm
Package weight: 39.5 kg
Logistics data
Harmonized System (HS) code: 8504408590
Country of origin: China
Other features
Battery type: RBP0076
