Cooler Master MasterLiquid Core Nex. Type: All-in-one liquid cooler, Fan diameter: 12 cm, Rotational speed (min): 650 RPM, Rotational speed (max): 1750 RPM, Airflow: 122.4 m³/h, Maximum air pressure: 1.86 mmH2O, Bearing type: Rifle bearing. Product colour: White
MasterLiquid Core Nex Series
Introducing the redesigned MasterLiquid Core Nex Series from Cooler Master. Built on the trusted foundation of the MasterLiquid series, the Core Nex brings improved cooling performance with its upgraded dual chamber pump and wider CPU compatibility for flexible PC builds. With the infinity mirror pump cover design, upgraded fans, and optimized tubing for easy installation, the MasterLiquid Core Nex Series is a smart and stylish cooling solution for mainstream users looking to step up their setup.
Innovative Design
An infinity mirror pump cover design brings stylish lighting and a modern touch to your build
Flexible Pump Orientation
Featuring a rotatable pump cover that allows users to customize the orientation for the perfect look.
Dual chamber pump
Patented design
Our latest patented dual chamber design has been refined for enhanced cooling synergy. The new design increases water pressure and optimizes water flow directly to CPU hot spot.
Improved Quality
Fully automated production and assembly of the pump with fully recorded production history.
Dual Chamber Pump
Our patented dual chamber design delivers a compact cooler with efficient and reliable performance.
Optimum Tubing Length
400 mm tubing allows for effortless cooler installation in any orientation.
Easy Installation
With pre-installed fans, streamlined cabling, pre-applied thermal paste, and pre-mounted brackets, setup is quick, clean, and effortless
Universal Socket Support
Broad compatibility with both Intel and AMD CPU sockets
Suitable location: Processor
Type: All-in-one liquid cooler
Fan diameter: 12 cm
Rotational speed (min): 650 RPM
Rotational speed (max): 1750 RPM
Maximum airflow: 71.9 cfm
Airflow: 122.4 m³/h
Maximum air pressure: 1.86 mmH2O
Feature: Pulse-width modulation (PWM) support
Bearing type: Rifle bearing
Fan noise level (max): 27.2 dB
Pump noise level: 25 dB
Pump connector: 3-pin + 4-pin
Quantity per pack: 1 pc(s)
Pump motor speed (max): 3200 RPM
Pump’s mean time to failure (MTTF): 35000 h
Fan’s mean time to failure (MTTF): 40000 h
Design
Product colour: White
Radiator material: Aluminum
Number of fans: 3 fan(s)
Feature: Illumination LED
Illumination colour: Red, Green, Blue
Fan connector: 7-pin
Display type: Not applicable
Power
Rated voltage: 12 V
Fan power consumption: 3.12 W
Pump power consumption: 7.2 W
Rated current: 0.26 A
Safety current: 0.37 Ah
Pump voltage: 12 V
Weight & dimensions
Radiator width: 12 cm
Radiator depth: 39.4 cm
Radiator height: 2.72 cm
Tube length: 40 cm
Pump width: 7.85 cm
Pump depth: 8.36 cm
Pump height: 6.29 cm
Weight: 1.65 kg
Fan dimensions (W x D x H): 120 x 120 x 25 mm
Package width: 229 mm
Package depth: 450 mm
Package height: 142 mm
Package weight: 2.73 kg
Logistics data
Master (outer) case width: 465 mm
Master (outer) case length: 475 mm
Master (outer) case height: 310 mm
Products per master (outer) case: 4 pc(s)
