Chieftec Task TPS-500S. Total power: 500 W, AC input voltage: 115 – 230 V, AC input frequency: 47 – 63 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Compliance certificates: RoHS, Certification: ErP, RoHS, CE, CB, EAC, TÜV
The CHIEFTEC Task Series PSU’s are true to their name, and take on any task they are required for without any trouble.
With certified 80PLUS® Bronze efficiency and all modern protection and safety features, the PSU can be trusted to deliver power efficiently and reliably. With cable lengths extended to 650mm for motherboard and CPU, these power supplies will also serve excellently for builds inside larger cases.
Power
Total power: 500 W
AC input voltage: 115 – 230 V
AC input frequency: 47 – 63 Hz
Power Factor Correction (PFC) type: Active
Combined power (+3.3V): 110 W
Combined power (+5V): 110 W
Max output current (+3.3V): 18 A
Max output current (+12V1): 38 A
Max output current (+5V): 17 A
Max output current (+5Vsb): 2.5 A
Efficiency: 85%
Power protection features: Over power, Over voltage, Overload, Short circuit
Ports & interfaces
Motherboard power connector: 24-pin ATX
Number of SATA power connectors: 5
Peripheral (Molex) power connectors (4-pin): 3
Feature: EPS power connector (4+4 pin)
PCI Express power connectors (6+2 pin): 2
Cabling type: Non-Modular
Performance
80 PLUS certification: 80 PLUS Bronze
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 2.3
Design
Product colour: Black
Cooling type: Active
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Fan location: Side
Feature: On/off switch
Certificates
Compliance certificates: RoHS
Certification: ErP, RoHS, CE, CB, EAC, TÜV
Weight & dimensions
Width: 150 mm
Depth: 140 mm
Height: 86 mm
Logistics data
Harmonized System (HS) code: 84733020
Total power: 500 W
AC input voltage: 115 – 230 V
AC input frequency: 47 – 63 Hz
Power Factor Correction (PFC) type: Active
Combined power (+3.3V): 110 W
Combined power (+5V): 110 W
Max output current (+3.3V): 18 A
Max output current (+12V1): 38 A
Max output current (+5V): 17 A
Max output current (+5Vsb): 2.5 A
Efficiency: 85%
Power protection features: Over power, Over voltage, Overload, Short circuit
Ports & interfaces
Motherboard power connector: 24-pin ATX
Number of SATA power connectors: 5
Peripheral (Molex) power connectors (4-pin): 3
Feature: EPS power connector (4+4 pin)
PCI Express power connectors (6+2 pin): 2
Cabling type: Non-Modular
Performance
80 PLUS certification: 80 PLUS Bronze
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 2.3
Design
Product colour: Black
Cooling type: Active
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Fan location: Side
Feature: On/off switch
Certificates
Compliance certificates: RoHS
Certification: ErP, RoHS, CE, CB, EAC, TÜV
Weight & dimensions
Width: 150 mm
Depth: 140 mm
Height: 86 mm
Logistics data
Harmonized System (HS) code: 84733020
