APC AP6032A. PDU types: Basic, Rack capacity: 0U/1U, Type: Single-phase. AC outlets quantity: 4 AC outlet(s), AC outlet types: C19 coupler, Power plug: IEC 60309. Cable length: 3.65 m. Nominal input voltage: 200-240 V, Maximum current: 32 A, AC input frequency: 50 – 60 Hz. Compliance certificates: RoHS, Certification: VDE, CE
The APC by Schneider Electric Basic Rack Power Distribution Unit (PDU) distributes power to devices in the rack.
Design
PDU types: Basic
Type: Single-phase
Rack capacity: 0U/1U
Mounting: Horizontal/Vertical
Product colour: Black
Ports & interfaces
AC outlets quantity: 4 AC outlet(s)
Power plug: IEC 60309
AC outlet types: C19 coupler
Features
Cable length: 3.65 m
Power
Nominal input voltage: 200-240 V
AC input frequency: 50 – 60 Hz
Maximum current: 32 A
Nominal output voltage: 200-240 V
Load capacity: 7680 VA
Maximum input current per phase: 32 A
Maximum power: 7680 W
Certificates
Compliance certificates: RoHS
Certification: VDE, CE
Operational conditions
Operating temperature (T-T): 0 – 50 °C
Storage temperature (T-T): -15 – 60 °C
Operating relative humidity (H-H): 5 – 95%
Storage relative humidity (H-H): 5 – 95%
Weight & dimensions
Width: 4.36 mm
Depth: 9.29 mm
Height: 43.8 mm
Weight: 2.78 kg
PDU types: Basic
Type: Single-phase
Rack capacity: 0U/1U
Mounting: Horizontal/Vertical
Product colour: Black
Ports & interfaces
AC outlets quantity: 4 AC outlet(s)
Power plug: IEC 60309
AC outlet types: C19 coupler
Features
Cable length: 3.65 m
Power
Nominal input voltage: 200-240 V
AC input frequency: 50 – 60 Hz
Maximum current: 32 A
Nominal output voltage: 200-240 V
Load capacity: 7680 VA
Maximum input current per phase: 32 A
Maximum power: 7680 W
Certificates
Compliance certificates: RoHS
Certification: VDE, CE
Operational conditions
Operating temperature (T-T): 0 – 50 °C
Storage temperature (T-T): -15 – 60 °C
Operating relative humidity (H-H): 5 – 95%
Storage relative humidity (H-H): 5 – 95%
Weight & dimensions
Width: 4.36 mm
Depth: 9.29 mm
Height: 43.8 mm
Weight: 2.78 kg
