AG Neovo 65-Inch 4K Commercial Display. Product design: Digital signage flat panel. Display diagonal: 163.8 cm (64.5"), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 700 cd/m², HD type: 4K Ultra HD. Operating hours (hours/days): 24/7. Product colour: Black
700 nits High Brightness
The PD-65Q commercial display features 4K UHD, 10-bit colour depth, and 178-degree viewing angle for brilliant colour performance. Besides that, the PD-Series adopts a 700 nits brightness commercial-grade panel to deliver clear, bright, and detailed imagery even in the daylight or bright indoor environments.
IPS Panel for 24/7 Use
Designed for 24/7 operation, the display is produced to meet the highest standard of IPS panel technology and take advantage of superior components to ensure a long product lifetime in demanding environments.
Landscape/Portrait Capability
This commercial-grade display is signage-friendly and can perfectly fit either in a landscape or in a portrait mode to experience complete screen orientation flexibility and fulfill the need in different scenarios.
Optional Intel® SDM Capability
The built-in SDM slot is designed for Intel® smart display module, which is ready to deliver a powerful smart signage functionality for more user-friendly applications.
Patented Anti-Burn-in™ Technology
To combat the effects of traditional LCD burn-in or ghosting, AG Neovo utilises its patented Anti-Burn-in Technology to prevent image burn-in and assure the extended life span for displays.
DisplayPort/IR/RS232 Daisy Chain Functionality
With DisplayPort daisy chain functionality, the video and audio can be delivered to multiple AG Neovo’s large format displays using DisplayPort cables, and it saves a significant amount of time. IR/RS232 loop-through capability provides a convenient single point of control for multi-display installation.
Embedded Image Enhancer
The embedded image enhancer features a 3D Comb Filter, 3D Deinterlace, and Noise Reduction to solve image issues – offering crystal clarity to the most demanding environments.
Integrated Content Scheduler
The built-in integrated scheduler in the OSD menu allows you to easily broadcast content based on source, time, and day by IR remote control.
PID Command & Ctrl Software
PID Command & Ctrl provides intuitive user interfaces for remote management via laptops and mobile devices and offers easy creation on video wall displays. The software also has simple colour calibration, temperature check, IR/key locking options, and time on usage monitoring for daily maintenance.
Panel type: IPS
Feature: LED backlight
Display diagonal: 163.8 cm (64.5″)
Display technology: LCD
Display resolution: 3840 x 2160 pixels
Display brightness: 700 cd/m²
HD type: 4K Ultra HD
Native aspect ratio: 16:9
Response time: 5 ms
Contrast ratio (typical): 1200:1
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Display number of colours: 1.07 billion colours
Pixel pitch: 0.372 x 0.372 mm
Number of displays: 1
Horizontal scan range: 31 – 92 kHz
Vertical scan range: 48 – 85 Hz
Native refresh rate: 60 Hz
Haze rate: 25%
Surface hardness: 2H
Colour gamut: 72%
Ports & interfaces
HDMI ports quantity: 3
HDMI version: 2.0
Feature: DVI port
DVI-I ports quantity: 1
DisplayPorts quantity: 2
DisplayPorts in: 1
DisplayPorts out: 1
Feature: USB port
USB ports quantity: 2
USB version: 2.0
Ethernet LAN (RJ-45) ports: 1
Feature: RS-232 interface
Feature: Infrared data port
Remote (IR) input: 1
Remote (IR) output: 1
Feature: Card reader integrated
Compatible memory cards: MicroSD (TransFlash)
Audio
Feature: Built-in speaker(s)
Number of built-in speakers: 2
RMS rated power: 10 W
Design
Product design: Digital signage flat panel
Placement supported: Indoor
Orientation: Horizontal/Vertical
Product colour: Black
Feature: VESA mounting
Panel mounting interface: 400 x 400 mm
Feature: Anti-glare screen
Performance
Purpose: Commercial
Operating hours (hours/days): 24/7
Power
Power consumption (standby): 0.4 W
Power consumption (off): 0 W
Energy efficiency class (SDR): G
Energy efficiency class (HDR): Not available
Energy consumption (SDR) per 1000 hours: 199 kWh
AC input voltage: 100 – 240 V
AC input frequency: 50 – 60 Hz
Energy efficiency scale: A to G
Weight & dimensions
Display width: 1462.3 mm
Display depth: 93.4 mm
Display height: 837.3 mm
Display weight: 27.8 kg
Packaging data
Package width: 1580 mm
Package depth: 151 mm
Package height: 1050 mm
Package weight: 33.9 kg
Packaging content
Feature: Remote control included
Feature: Batteries included
Cables included: AC, HDMI
Operational conditions
Operating temperature (T-T): 0 – 40 °C
Operating relative humidity (H-H): 20 – 80%
Storage temperature (T-T): -20 – 60 °C
Storage relative humidity (H-H): 10 – 90%
Certificates
Certification: FCCCELVDICES-003(Issue 7)WEEERoHSREACH
Logistics data
Harmonized System (HS) code: 85285210
Network
Feature: Ethernet LAN
Features
Feature: Wall mountable
Technical details
I/O ports: SDM Slot
Compliance certificates: RoHS
Other features
Feature: Quick start guide
Audio input: 1
Audio output: 1
RS-232 input ports: 1
RS-232 output ports: 1
Power supply type: Internal
