Synology RackStation RS822RP+. Type: NAS. Chassis type: Rack (1U). Device class: Small & Medium Business. Processor family: Ryzen Embedded, Processor model: V1500B, Processor frequency: 2.2 GHz. Internal memory: 2 GB, Internal memory type: DDR4. Total installed storage capacity: 0 TB. Operating system installed: DiskStation Manager
The compact 1U 4-bay Synology RackStation RS822+/RS822RP+ with its storage and connectivity expandability coupled with the powerful Synology DiskStation Manager (DSM) operating system is an ideal edge storage solution for branch offices and small and medium-sized businesses.
Built for reliability
RS822+/RS822RP+ comes with four Gigabit RJ-45 ports which can be bonded with Link Aggregation to enable automatic network failover and load balancing.
Two RS822+/RS822RP+ units can be paired using Synology High Availability to form a reliable active/passive server cluster, maximizing service uptime.
Furthermore, the RS822RP+ features a redundant power supply for an extra edge in service continuity.
Room for expansion
Easily adjust the RS822+/RS822RP+ to match your usage environment, whether it needs performance, faster networking, or higher storage capacity.
All-in-one data management platform
The RS822+/RS822RP+ is designed to support small deployments in tackling common applications such as file management, data backup, and surveillance.
Edge storage for distributed teams
Provide secure and convenient cross-platform file access, sharing, and synchronization across multiplelocations.
Multi-endpoint data protection
Design an effective backup strategy to maximize system availability with a host of native and license-free solutions.
Smart surveillance for small deployments
Leverage flexible deployment options, intuitive management capabilities, and advanced video analytics to secure your premises.
Works best with Synology drives
Enjoy high sustained performance and reliability with enterprise-grade drives designed for Synology NAS and featuring built-in data protection.
Powered by Synology DSM
Take advantage of a whole host of native productivity, management, and security solutions available on the web-based DSM operating system.
Supported storage drive interfaces: Serial ATA II, Serial ATA III
Storage drive sizes supported: 2.5,3.5″
RAID support: Yes
RAID levels: 0, 1, 5, 6, 10, JBOD
Online RAID migration: Yes
Online RAID expansion: Yes
Hot-swap drive bays: Yes
Supported file systems: BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
Storage drives installed: No
Total installed storage capacity: 0 TB
Number of storage drives supported: 4
Installed storage drive type: No
Supported storage drive types: HDD & SSD
Processor
Processor manufacturer: AMD
Processor generation: AMD Ryzen Embedded V1000 Series
Processor family: Ryzen Embedded
Processor model: V1500B
Processor frequency: 2.2 GHz
Processor cores: 4
Processor threads: 8
L2 cache: 2 MB
L3 cache: 4 MB
Number of processors supported: 1
On-board graphics card model: Not available
Memory
Internal memory: 2 GB
Internal memory type: DDR4
Maximum RAM supported: 32 GB
Memory slots: 2
Memory form factor: SO-DIMM
ECC: Yes
Network
Ethernet LAN: Yes
Ethernet LAN data rates: 1000 Mbit/s
iSCSI support: Yes
Wake-on-LAN ready: Yes
Supported network protocols: SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Link aggregation: Yes
WLAN adapter supported: Yes
Ports & interfaces
USB port: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
eSATA ports quantity: 1
Ethernet LAN (RJ-45) ports: 4
Concurrent connections: 500
PCI Express x8 (Gen 3.x) slots: 1
Design
Chassis type: Rack (1U)
Cooling type: Active
Product colour: Grey
Number of fans: 2 fan(s)
Fan diameter: 4 cm
Drive bay locking: Yes
LED indicators: Alarm, HDD, Power, Status
Performance
Type: NAS
Device class: Small & Medium Business
Backup function: Yes
Backup features: Cloud, iSCSI LUN
Multilingual support: Yes
Number of users: 2048 user(s)
Noise level: 38.8 dB
Third-party support: Yes
Snapshot: Yes
Security algorithms: HTTPS, SSH, SSL/TLS
Access Control List (ACL): Yes
Reset button: Yes
On/off switch: Yes
Built-in iTunes server: Yes
Built-in FTP server: Yes
Browser supported: Google Chrome, Firefox, Microsoft Edge, Safari
System log: Yes
Hot spare: Yes
Share folder: SMB/AFP/NFS/FTP/WebDAV
Software
Operating system installed: DiskStation Manager
Windows operating systems supported: Yes
Linux operating systems supported: Yes
Mac operating systems supported: Yes
Power
Power supply location: Built-in
Power supply unit (PSU) capacity: 150 W
Redundant power supply (RPS) support: Yes
Power consumption (typical): 47.69 W
Power consumption (HDD standby): 16.7 W
AC input voltage: 100 – 240 V
AC input frequency: 50/60 Hz
Weight & dimensions
Width: 480 mm
Depth: 518.6 mm
Height: 44 mm
Weight: 8 kg
Packaging content
Cables included: AC
Power cables quantity: 2
Operational conditions
Operating temperature (T-T): 0 – 35 °C
Operating relative humidity (H-H): 8 – 80%
Storage temperature (T-T): -20 – 60 °C
Storage relative humidity (H-H): 5 – 95%
Operating altitude: 0 – 5000 m
Other features
Compliance certificates: RoHS
Certification: FCC CE BSMI VCCI RCM UKCA EAC CCC KC UL
